AXIS T8524 T85 Series 24-Port PoE+ Network Switch
01192-004|Z4-01192004
AXIS T8524 T85 Series 24-Port PoE+ Network Switch
01192-004|Z4-01192004
Key Features
- 2 SFP/RJ45 Combination Ports
- 30 W PoE per port, total 370 W
- Gigabit switch
Key Features
- 2 SFP/RJ45 Combination Ports
- 30 W PoE per port, total 370 W
- Gigabit switch
Sign In for Dealer Pricing
Become an ADI CustomerKey Features
- 2 SFP/RJ45 Combination Ports
- 30 W PoE per port, total 370 W
- Gigabit switch
Axis Communications
AXIS T8524 T85 Series 24-Port PoE+ Network Switch
01192-004 | Z4-01192004
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
AXIS T8524 PoE+ Network Switch is an easy to install 24-port managed Gigabit switch - a perfect complement to Axis’ recorders to further simplify setup and installation of surveillance systems. AXIS T8524 comes with an integrated DHCP server for automatic assignment of IP addresses and discovery of connected Axis devices. The intuitive administrator interface offers a graphic topology for easy overview of all devices in the system with information about connected devices and status. The high PoE power output allows for connection of up to 24 PoE cameras.
Main Features
- 2 SFP/RJ45 Combination Ports
- 30 W PoE per port, total 370 W
- Gigabit switch
- Intuitive graphic topology for system overview
General Information
Name: AXIS T8524 T85 Series 24-Port PoE+ Network Switch
Category: Axis Communications, Video Surveillance, Data Comm & Networking, Networking Devices, Hubs, Routers & Switches, Network Switches, Network Switches
UPC Code: 7331021061873
Country of Origin: TW. Country of origin is subject to change.
Specifications
-
ADI Part Number Z4-01192004 Brand Name AXIS Communications Manufacturer Axis Communications Manufacturer Part Number 01192-004 Product Line T Product Model T8524 Product Name AXIS T8524 POE+ NETWORK SWITCH US Product Series T85 Product Type Network Switches Weight 7.1 lb
-
Media Type Supported Optical Fiber, Twisted Pair Network Switch Type Managed
-
NDAA Compliant Yes TAA Compliant Yes
-
Operating Temperature (T-T) 0-50°C
-
Expansion Slot Type SFP Number of SFP Slots 2 Number of Total Expansion Slots 2 Shared SFP Slot Yes
-
Modular Yes Network (RJ-45) Yes Total Number of Network Ports 24 Uplink Port Yes
-
Manageable Yes Security Features IEC/EN 60950-1|IEC/EN 62368-1|UL 60950-1
-
Network Technology 1000Base-X
-
Ethernet Technology Gigabit Ethernet Layer Supported 2 Networking Standards IEEE 802.1x
-
Color Black Depth 8.31" Height 1.73" Width 17.4"
-
Frequency 50 Hz|60 Hz Input Voltage 100V AC, 230V AC Maximum Power Consumption 92W PoE (RJ-45) Port Yes PoE Budget 30W Power Source Power Supply
-
Mount Type Desktop Mount
-
Limited Warranty 5-Year
-
Certifications EN 55024, EN 55032 Class A, EN 55035, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), RCM AS/NZS CISPR 32 Class A, VCCI Class A Country of Origin TW Features 2 x Combination RJ45/SFP Ports, 24 x Gigabit Ethernet Ports, 30W PoE Power per Port, 370W PoE Power Budget, 38.7Mpps Throughput, 52 Gb/s Switching Capacity, 8K MAC Address Table, 9216Bytes Jumbo Frame
