AXIS 02857-001 HDTV 1080p Mk II Modular Standard IP Camera, 111° Field of View, 2.8mm Lens
02857-001
|Z4-02857001
Shop All Axis Communications
AXIS 02857-001 HDTV 1080p Mk II Modular Standard IP Camera, 111° Field of View, 2.8mm Lens
02857-001 | Z4-02857001
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
Based on the modular concept, AXIS P1245 Mk II features a thumb-sized sensor unit that connects via cable to the main unit, so the two parts can be placed separately from each other. This sensor unit is easy to install in tight spaces and can be recessed mounted to blend into the environment. Ideal for a wide range of indoor applications. The sensor can be mounted up to 15 m from the main unit and a detachable cable ensures flexible installation and upgrade. Additionally, a deep learning processing unit enables the use of advanced analytics.
Specifications
ADI Part Number Z4-02857001 Brand Name AXIS Communications Manufacturer Part Number 02857-001 Product Name AXIS P1245 Mk II Product Type Fixed cameras Supported Network Protocols IPv6 USGv6, NIST SP500-267
Aperture f/2.0 Field of View Horizontal, Vertical Lens Mount Type M12 Lens Type Fixed Maximum Aperture f/2 Maximum Frame Rate 30fps Video Formats H.264 (MPEG-4 Part 10/AVC), H.265 (MPEG-H Part 2/HEVC), MJPEG
Image Sensor Type CMOS Wide Dynamic Range Yes
Ingress Protection Rating IP3X
Image Sensor Size 1/2.9" Maximum Video Resolution 1920 x 1080
Maximum Operating Temperature 113°F Minimum Operating Temperature -4°F Operating Humidity 10-85%
Longest Shutter Speed 1/5 Second Minimum Illumination 0.2 lux Shortest Shutter Speed 1/16500 Second
Focal Length 2.8mm Lens Included Yes Maximum Focal Length 2.8mm
Memory Card Supported Yes
ADI Part Number Replaces Z4-0926001 Model Number Replaces 0926-001, P1245
Color White Depth 0.63" Form Factor Modular Height 4.66" Package Type Box Width 1.79"
Maximum Power Consumption 4W Power over Ethernet (PoE) Yes
Mount Type Recessed Mount
Storage Type Memory Card
Limited Warranty 5-Year
Certifications CISPR 32 Class A, CISPR 35, EN 55032 Class A, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES(A)/NMB(A), KS C 9832 Class A, KS C 9835, RCM AS/NZS CISPR 32 Class A, VCCI Class A Certifications & Standards ONVIF G, ONVIF M, ONVIF S, ONVIF T Environmental Certification EU RoHS, REACH, RoHS Environmentally Friendly Yes Features AXIS Object Analytics pre-installed, Detachable cable up to 15 m, HDTV 1080p with 111° field of view, Small, thumb-sized sensor unit, Support for analytics with deep learning Indoor/Outdoor Indoor Package Contents 2 locking nuts, 8 m (26 ') black cable, Installation Guide, Owner authentication key Main unit, Sensor unit
