Vanco PA2X25 2-Channel PulseAudio, Class D Amplifier, 25W, RCA and 1/8" Stereo Inputs
Brand: Vanco
ADI #:ZX-PA2X25
Model #: PA2X25
Name: Vanco PA2X25 2-Channel PulseAudio, Class D Amplifier, 25W, RCA and 1/8" Stereo Inputs
- Stereo and Mono/Bridge Modes
- Mixes audio when both inputs are connected and live
- Automatically goes into standby after 5 minutes of inactivity
Product Overview
General Information
Name : Vanco PA2X25 2-Channel PulseAudio, Class D Amplifier, 25W, RCA and 1/8" Stereo Inputs , VancoCategory : Amplifiers
UPC Code : 741835108928
Country of Origin : China. Country of origin is subject to change.
Specifications
General Information
ADI Part Number : ZX-PA2X25
Brand Name : Vanco
Manufacturer : Vanco International, Inc
Manufacturer Part Number : PA2X25
Product Model : PA2X25
Product Name : 2 Channel, Class D Amplifier - 25W
Product Type : Amplifier
Weight (Approximate) (g) : 600
Technical Information
Audio Channels : 2
Classification : D
Impedance : 8 Ohm
Impedance (Ohm) : 8
Maximum Frequency Response (Hz) : 20000
Minimum Frequency Response (Hz) : 20
Audio
Maximum Frequency Response : 20 kHz
Minimum Frequency Response : 20 Hz
RMS Output Power : 50 W
RMS Output Power (W) : 50
Energy & Performance
Operating Power Consumption : 60 W
Operating Power Consumption (W) : 60
Interfaces/Ports
Number of Analog Audio Inputs : 2
Physical Characteristics
Depth : 3.7"
Depth (mm) : 95
Height : 1.8"
Height (mm) : 45
Weight (Approximate) : 1.32 lb
Width : 5.6"
Width (mm) : 143
Power Description
Input Voltage : 120 V AC, 230 V AC
Input Voltage (V AC) : 120, 230
Miscellaneous
Country of Origin : China
Package Contents : <ul> <li>2 Channel, Class D Amplifier - 25W</li> <li>Power lead cable</li> <li>1- 4 conductor Phoenix connector (screw down terminal)</li> <li>Mounting bracket and screws</li> <li>Product Manual</li> </ul>
