Digital Watchdog DWC-MB45WIATW MEGApix IVA 5MP IR Bullet IP Camera, 2.7-13.5mm Varifocal Lens, White (Replaces DWC-MB45WIAT)
DWC-MB45WIATW | 6K-MB45WIATW
Please sign in to view pricing and availability and to add to cart.
Product Overview
IVA Analytics
MEGApix IVA cameras have a powerful engine to detect and classify people and vehicles in real-time. IVA+ license upgrade offers advanced video content analysis detection capabilities.
Logical Rules
Logical Rules combine multiple zones and virtual tripwires linked together for a greater event detection level while reducing unwanted false alarms/positives.
IVA integrates seamlessly with DW Spectrum IPVMS
MEGApix IVA analytics are seamlessly integrated with DW Spectrum IPVMS for easy configuration, real-time alerts and automatic notifications.
Reduce false alarms
MEGApix IVA's intelligent algorithms offer better object classification and identify environmental elements. The result is a substantial reduction in false alarms for control room operators and security personnel. By allowing only valid events to filter through MEGApix IVA cameras increase efficiency, productivity and cut unnecessary costs.
Star-Light Plus color in darkness technology
Star-Light Plus color in near-total darkness technology provides crisp, clear images in the absence of ambient light.
Cold Start -40°F (-40°C)
The installed heater helps the camera power up in extreme cold weather conditions where temperatures may go as low as -40°F. This makes the cameras ideal for any harsh environment installation.
Main Features
- Reduce false alarms
- Intelligent Video Analytics (IVA)
- True Wide Dynamic Range (WDR)
- 140' Smart IR with intelligent camera sync
- 5MP 1/2.8" image sensor at real-time 30fps
- Extended Intelligent Video Analytics (IVA+ required)
- Star-Light Plus color in near-total darkness technology
- Triple codecs (H.265, H.264, MJPEG) with simultaneous streaming
- Increase your recording storage with logic rules and smart recording
- 2.7-13.5mm vari-focal p-iris lens with motorized zoom and auto-focus
General Information
Specifications
-
ADI Part Number 6K-MB45WIATW Brand Name Digital Watchdog Manufacturer Digital Watchdog Manufacturer Part Number DWC-MB45WIATW Product Line MEGApix Product Model DWC-MB45WIATW Product Name MEGApix IVA 5MP bullet IP camera with a vari-focal lens, IR and IVA Product Series MB45 Product Type Network Camera Weight 1.98 lb
-
Connectivity Technology Wired Effective Camera Resolution 5MP Field of View HFOV / VFOV 85° - 31° / 62° - 24° Lens Type Varifocal Maximum Aperture f/1.4 Maximum Frame Rate 30 fps Minimum Focal Length 2.7mm Night Vision Yes Night Vision Type Infrared Optical Zoom 5x Video Formats H.264, H.265, MJPEG
-
Image Sensor Type CMOS Night Vision Distance 140 ft Wide Dynamic Range Yes
-
Ingress Protection Rating IP66
-
Maximum Video Resolution 2592 x 1944
-
Maximum Operating Temperature 122°F (50°C) Minimum Operating Temperature -40°F (-40°C) Operating Humidity 90%
-
Longest Shutter Speed 1/15 Second Shortest Shutter Speed 1/32000 Second
-
Focal Length 2.7-13.5 mm Lens Included Yes Maximum Focal Length 13.5 mm
-
Remote Management Yes
-
ADI Part Number Replaces 6K-MB45WIAT Model Number Replaces DWC-MB45WIAT
-
Color White Durability Dust Resistant, Waterproof, Weather Resistant Form Factor Bullet
-
Input Voltage 12V DC
-
Mount Type Ceiling Mount, Wall Mount
-
Storage Type Memory Card
-
Analog Video Signal Format CVBS Maximum Resolution 1280 x 720
-
Limited Warranty 5-Year
-
Country of Origin VN Environmental Certification RoHS Environmentally Friendly Yes Features 3D Noise Reduction, Auto Flip, Auto Gain Control, Automatic White Balance, Back Light Compensation (BLC), Cross Line Detection, Day/Night, Defog, Mirror, Motion Detection, PTZ, Tamper Detection, Wide Dynamic Range
