GRI 194-12 1" Steel Door Recessed Switch Set, Standard Gap, 5W, 175VDC, 0.25 Amp, Open/Closed SPDT, C, Black
GRI 194-12 1" Steel Door Recessed Switch Set, Standard Gap, 5W, 175VDC, 0.25 Amp, Open/Closed SPDT, C, Black
GRI 194-12 1" Steel Door Recessed Switch Set, Standard Gap, 5W, 175VDC, 0.25 Amp, Open/Closed SPDT, C, Black
194-12Â |Â GI-19412BL
Please sign in to view pricing and availability and to add to cart.
Product Overview
The GRI 180 Series is the industry standard 3/4" diameter recessed steel door switch set with 12" leads. The 184 Series is a 1" diameter switch set.
The innovative GRI 8080-T Series is a 3/4" diameter recessed switch set designed for residential, commercial and industrial steel doors and frames. The shorter length and the introduction of PC board type terminals makes the installation of the set quick and simple with no soldering, B connectors or tape to catch during installation or removal, reducing the cost of installation and creating greater profitability.
Main Features
- Lifetime Warranty
- Colors:White, Brown, Grey or Black
- UL and ULC Approved
- 180-12 & 184-12 UL 10C Fire Rated
- Available in Closed Loop, Open Loop and SPDT
- 3/4" and 1" Diameter Mounting
- Standard 12" Leads or Terminals
- Self-Locking
- Solid, One Piece Design
- 7/8" Diameter also Available - Call Factory
General Information
Specifications
-
ADI Part Number GI-19412BL Brand Name George Risk Industries Manufacturer George Risk Industries Manufacturer Part Number 194-12-BL Product Model 194-12-BL Product Name 194-12-BL Magnetic Contact Product Type Magnetic Contact Â
-
Connectivity Technology Wired Contact Configuration SPDT Contact Form Form C Contact Resistance 140000 Micro Ohm Contact Resistance (Ohm) 0.14 Lead Length 12" Lead Length (mm) 304.8 Mounting Type Recessed Mount Recommended Use Door Standard Gap 0.5" Standard Gap (mm) 12.7 Â
-
Application/Usage Commercial, Industrial, Residential Color Black Color Family Black Diameter (mm) 25.4 Product Color Black Product Material Steel Â
-
Power Source DC Â
-
Contact Type Closed Loop, Open Loop Diameter 1" Installation Type Commercial Â
-
Limited Warranty Lifetime Â
-
Additional Information - Switches or Magnets are Available Separately
- Wide Gap 1"+ Gap on Steel
- Supervisory Loops Available
Features End of Line (EOL) Resistor, Self-lock Mounting Â
