GRI 29C 29 Series Surface Mount Magnetic Reed Switch Set, 1" Standard Gap, 5W, 175VDC, 0.25A, SPDT, and Side Mounted Screw Terminals, Brown
29C|GI-29CBR
Color: Brown
GRI 29C 29 Series Surface Mount Magnetic Reed Switch Set, 1" Standard Gap, 5W, 175VDC, 0.25A, SPDT, and Side Mounted Screw Terminals, Brown
29C|GI-29CBR
Color: Brown
George Risk Industries
GRI 29C 29 Series Surface Mount Magnetic Reed Switch Set, 1" Standard Gap, 5W, 175VDC, 0.25A, SPDT, and Side Mounted Screw Terminals, Brown
29C | GI-29CBR
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
This series offers a standard gap of 1 inch, a wide gap of up to 1 1/2 inches and an extra wide gap of 2 inches and can be installed on a steel surface with a minimum gap penalty. The “P” style is a pre-wired switch with 2 feet of conductor cable. A broad range of mounting brackets are also available.
Main Features
- The GRI 29C-B is a brown magnetic reed switch designed for surface mounting.
- The unit is equipped with a open loop system, top terminals; covers. The switch offers a standard gap of up to 1 and 5/8 on steel.
- The switch offers a standard gap of up to 1? and 5/8? on steel.
- 24" jacketed cable on PA Series
- Longer leads upon request on PA series
- Side mounted screw terminals on 29 series
- Standard gap up to 1", 5/8" on steel
- Wide gap up to 1 1/2", 3/4" on steel
- Extra wide gap up to 2", 1" on steel
- Spacers, covers and screws Included
General Information
Name: GRI 29C 29 Series Surface Mount Magnetic Reed Switch Set, 1" Standard Gap, 5W, 175VDC, 0.25A, SPDT, and Side Mounted Screw Terminals, Brown
Category: George Risk Industries, Intrusion, Alarm Contacts, Magnetic Contacts
UPC Code: 697625007103
Country of Origin: United States. Country of origin is subject to change.
Specifications
-
ADI Part Number GI-29CBR Brand Name George Risk Industries Manufacturer George Risk Industries Manufacturer Part Number 29C-B Product Model 29C Product Name 29C Magnetic Contact Product Series 29 Product Type Magnetic Contact
-
Connectivity Technology Wired Contact Configuration SPDT Mounting Type Surface Mount Standard Gap 1" Standard Gap (mm) 25.4
-
Color Brown Product Color Brown Product Material Steel
-
Power Source DC
-
Contact Type Closed Loop, Open Loop Installation Type Commercial
-
Limited Warranty Lifetime
-
Additional Information - Surface mount magnetic contacts
- Screw down flanges
- Hermetically sealed
- Plated contacts resist sticking or freezing
- SPDT
Package Contents - 29C Magnetic Contact
- Covers
- Spacers
- Mounting Hardware
