AXIS P3818-PVE P38 Series 13MP Outdoor Vandal Resistant 180° Panoramic Fixed Dome IP Camera, 3.2mm Fixed Lens, White
P3818-PVE|Z4-02060001
AXIS P3818-PVE P38 Series 13MP Outdoor Vandal Resistant 180° Panoramic Fixed Dome IP Camera, 3.2mm Fixed Lens, White
P3818-PVE|Z4-02060001
Key Features
- 13 MP multisensor camera with one IP address
- 180° horizontal, 90° vertical coverage
- Built-in cybersecurity features
Key Features
- 13 MP multisensor camera with one IP address
- 180° horizontal, 90° vertical coverage
- Built-in cybersecurity features
Sign In for Dealer Pricing
Become an ADI CustomerKey Features
- 13 MP multisensor camera with one IP address
- 180° horizontal, 90° vertical coverage
- Built-in cybersecurity features
Axis Communications
AXIS P3818-PVE P38 Series 13MP Outdoor Vandal Resistant 180° Panoramic Fixed Dome IP Camera, 3.2mm Fixed Lens, White
P3818-PVE | Z4-02060001
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
AXIS P3818-PVE delivers a 180º panoramic overview of extensive areas with ultra-high resolution images and incredible details up to 30 fps. With 13 MP resolution and seamless stitching of all three images, it offers 180° horizontal and 90° vertical coverage with no blind spots. Including a variety of mounting options, it’s also possible to mount two cameras back-to-back for a complete 360° overview, using AXIS T94V01C Dual Camera Mount. Featuring edge-to-edge technology, it’s easy to add support for audio enabling you to listen in to transactions or incidents. Additionally, built-in cybersecurity features prevent unauthorized access and safeguard your system.
Main Features
- 13 MP multisensor camera with one IP address
- 180° horizontal, 90° vertical coverage
- Built-in cybersecurity features
- Seamlessly stitched images
- Support for audio input
General Information
Name: AXIS P3818-PVE P38 Series 13MP Outdoor Vandal Resistant 180° Panoramic Fixed Dome IP Camera, 3.2mm Fixed Lens, White
Category: Axis Communications, Video Surveillance, IP Cameras, Panoramic Cameras
UPC Code: 7331021071742
Country of Origin: Mexico. Country of origin is subject to change.
Specifications
-
ADI Part Number Z4-02060001 Brand Name AXIS Communications Manufacturer Axis Communications Manufacturer Part Number 02060-001 Product Line P Product Model P3818-PVE Product Name AXIS P3818-PVE Product Series P38 Product Type Fixed dome cameras Supported Network Protocols IPv6 USGv6|NIST SP500-267 Weight 4.85lb
-
Aperture f/2.0 Connectivity Technology Wired Effective Camera Resolution 13MP Field of View Horizontal, Vertical Lens Type Fixed Maximum Aperture f/2 Maximum Frame Rate 30 fps Minimum Focal Length 3.2mm Night Vision Yes Video Formats H.264, H.265, MJPEG, MPEG-4
-
Image Sensor Type CMOS Wide Dynamic Range Yes
-
Ingress Protection Rating IP66, IP67 TAA Compliant Yes
-
Image Sensor Size 1/2.8" Maximum Video Resolution 5120 x 2560
-
Maximum Operating Temperature 122°F (50°C) Minimum Operating Temperature -40°F (-40°C) Operating Humidity 100% Operating Temperature (T-T) -40-50°C
-
Longest Shutter Speed 1/25 Second Minimum Illumination 0.05 lux Shortest Shutter Speed 1/91000 Second
-
Network (RJ-45) Yes
-
Focal Length 3.2mm Lens Included Yes Maximum Focal Length 3.20 mm
-
Memory Card Supported Yes
-
Remote Management Yes
-
Color White Durability Vandal Resistant Form Factor Dome Height 6.7"
-
Maximum Power Consumption 18W Power over Ethernet (PoE) Yes
-
Diameter 7.7" Mount Type Ceiling Mount, Junction Box Mount, Pendant Mount, Pole Mount, Recessed Mount, Wall Mount
-
Recording Formats 4K Storage Type Memory Card
-
Maximum Resolution 1280 x 720
-
Limited Warranty 5-Year
-
Certifications CISPR 24, CISPR 35, EAC, EN 50121-4, EN 55024, EN 55032 Class A, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), IEC 62236-4, KC KN32 Class A, KC KN35, RCM AS/NZS CISPR 32 Class A, VCCI Class A Certifications & Standards ONVIF G, ONVIF M, ONVIF S, ONVIF T Country of Origin MX Environmental Certification IEC 60068-2-1, IEC 60068-2-14, IEC 60068-2-2, IEC 60068-2-27, IEC 60068-2-6, IEC 60068-2-78, IEC/EN 60529 IP66, IEC/EN 60529 IP67, IEC/EN 62262 IK10, NEMA 250 Type 4X, NEMA TS 2 (2.2.7-2.2.9) Features Active Tampering Alarm, Audio Detection, Auto Gain Control, Built-in Microphone, Day/Night, HTTPS Encryption, Motion Detection, Noise Reduction, Password Protection, Privacy Masking, Removable IR Cut-off Filter, SD Card Local Storage, White Balance, Wide Dynamic Range Impact Protection Rating IK10 Indoor/Outdoor Outdoor
