Product Overview
The Bogen TPU Series Mixer-Amplifiers are unique, wall- or rack-mounted amplifiers, specifically designed for telephone paging applications. These compact units provide voice-activated muting of music when paging, completely eliminating the need for manual activation of switches and the use of external relays. The page channel features automatic output leveling (ALC) as channel input varies, which is particularly important in telephone paging applications, where persons with varying voice levels and paging techniques have access to the system. Installation and maintenance are simple; all connections, adjustments, and mounting are accomplished with a screwdriver.
Main Features
- 25V, 70V, or 8 Ohms output
- Compact wall-mount design
- Inputs for 600 Ohms balanced telephone line and background music
- Built-in night ringer triggered by external contact closure
- Integral automatic level control (ALC) circuit
- Signal-activated music muting circuit
- Individual controls for tone, page volume, background music volume, night ringer volume
- Lo-cut switch
- LED overload indicator
- Circuit breaker
General Information
Name: Bogen TPU600-G2 TPU Series Telephone Paging Amplifier, 600W
Category: Bogen, Pro AV, Commercial Audio, Pro Amplifiers
UPC Code: 765368200768
Country of Origin: Taiwan. Country of origin is subject to change.
Specifications
ADI Part Number BO-TPU600G2 Brand Name Bogen Manufacturer Bogen Manufacturer Part Number TPU600-G2 Product Model TPU600-G2 Product Name TPU Series TPU600-G2 mixer-Amplifier Product Series TPU Product Type Amplifier
Depth 13.48" Height 3.43" Width 8"
Input Voltage 100-240V AC
