Honeywell HC60W35R2 60 Series 5MP Indoor WDR IR IP Dome Camera, 2.7-13.5mm Lens, Lyric White
HC60W35R2|HC60W35R2
Honeywell HC60W35R2 60 Series 5MP Indoor WDR IR IP Dome Camera, 2.7-13.5mm Lens, Lyric White
HC60W35R2|HC60W35R2
Key Features
- 1/2.8" 5MP progressive scan imager
- 7~22 mm, F1.6~F2.9, MFZ lens
- Angle of view 39~16° (H) - 29~12° (V)
Key Features
- 1/2.8" 5MP progressive scan imager
- 7~22 mm, F1.6~F2.9, MFZ lens
- Angle of view 39~16° (H) - 29~12° (V)
Sign In for Dealer Pricing
Become an ADI CustomerKey Features
- 1/2.8" 5MP progressive scan imager
- 7~22 mm, F1.6~F2.9, MFZ lens
- Angle of view 39~16° (H) - 29~12° (V)
Honeywell Commercial Security
Honeywell HC60W35R2 60 Series 5MP Indoor WDR IR IP Dome Camera, 2.7-13.5mm Lens, Lyric White
HC60W35R2 | HC60W35R2
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
The 60 Series cameras are a perfect fit for dealers who are looking to sell simple, larger enterprise solutions to the compliant marketplace. The solution fits enterprise and critical applications where compliance is essential, such as Government, Utilities, Premium, Commercial, Retail, Campuses...
Main Features
- 1/2.8" 5MP progressive scan imager
- 7~22 mm, F1.6~F2.9, MFZ lens
- Angle of view 39~16° (H) - 29~12° (V)
- Best Main Stream: 2560x1920 (1 ~ 25/30fps), 1920x1080 (1 ~ 50/60fps)
- Best Sub Stream: 2560x1920 (1 ~ 25/30fps), 1920x1080 (1 ~ 50/60fps)
- Best Third Stream: 1280x960 (1 ~ 25/30fps), 1280x720 (1 ~ 50/60fps)
- Wide Dynamic Range (WDR) up to 120 dB
- Low light performance (0.04 lux in color mode)
- Up to 30 m (98 ft) IR distance, depending on scene reflectance
- H.265 Smart Codec video compression
General Information
Name: Honeywell HC60W35R2 60 Series 5MP Indoor WDR IR IP Dome Camera, 2.7-13.5mm Lens, Lyric White
Category: Honeywell Commercial Security, Video Surveillance, IP Cameras, Dome Cameras, ADI Pro Rewards
UPC Code: 886618404917
Country of Origin: Taiwan. Country of origin is subject to change.
Specifications
-
ADI Part Number HC60W35R2 Brand Name Honeywell Commercial Security Manufacturer Honeywell International, Inc Manufacturer Part Number HC60W35R2 Product Model HC60W35R2 Product Name 5MP Network TDN WDR IR Indoor Dome Camera Product Series 60 Product Type Network Camera Weight 1.28 lb
-
Connectivity Technology Wired Effective Camera Resolution 5MP Field of View H: 100° ~ 30°, V: 72° ~ 23° Lens Type Varifocal Maximum Aperture f/1.4 Maximum Frame Rate 60 fps Minimum Focal Length 2.7mm Night Vision Yes Night Vision Type Infrared Number of IR LEDs 4 Optical Zoom 5x Video Formats H.264, H.265, MJPEG Video Signal Format NTSC, PAL
-
Image Sensor Type CMOS Night Vision Distance 98.43 ft Wide Dynamic Range Yes
-
Ingress Protection Rating IP52 TAA Compliant Yes
-
Maximum Video Resolution 2560 x 1920
-
Maximum Operating Temperature 140°F (60°C) Minimum Operating Temperature 14°F (-10°C) Operating Humidity 90%
-
Longest Shutter Speed 1/30 Second Shortest Shutter Speed 1/32000 Second
-
Network (RJ-45) Yes
-
Focal Length 2.7-13.5 mm Lens Included Yes Maximum Focal Length 13.5 mm Minimum Aperture f/2.8
-
Remote Management Yes
-
Color White Durability Dust Resistant, Impact Resistant Form Factor Dome Height 4.8"
-
Input Voltage 12V DC, 24V AC
-
Diameter 5" Mount Type Ceiling Mount, Flush Mount, Wall Mount
-
Recording Formats HD Storage Type Memory Card
-
Maximum Resolution 1280 x 720
-
Country of Origin TW Environmental Certification RoHS Environmentally Friendly Yes Features 3D Digital Noise Reduction, Automatic White Balance, Back Light Compensation (BLC), Built-in Microphone, Cross Line Detection, Day/Night, Gain Control, Highlight Compensation (HLC), Motion Detection, Password Protection, Privacy Masking, Region of Interest, SD Card Local Storage, Wide Dynamic Range Impact Protection Rating IK10 Indoor/Outdoor Indoor
