Evolution EVSP24VW Evolution Expandable 4k 2x4 HDMI Video Wall Processor
EVSP24VW|ZX-EVSP24VW
Evolution EVSP24VW Evolution Expandable 4k 2x4 HDMI Video Wall Processor
EVSP24VW|ZX-EVSP24VW
Evolution by Vanco
Evolution EVSP24VW Evolution Expandable 4k 2x4 HDMI Video Wall Processor
EVSP24VW | ZX-EVSP24VW
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
The Evolution by Vanco EVSP24VW 4K Video Wall processor allows a source signal to be displayed across multiple displays to create a video wall. Equipped with two HDMI 2.0 inputs to connect multiple sources, with four outputs to create a video wall out of the box in multiple configurations. Need to create a larger video wall? Not a problem, the EVSP24VW features HDMI loop-outs to daisy-chain multiple units together up to a 16x16 configuration! Also features audio options including toslink digital audio output and balanced analog outputs, to break out into an amplifier or distributed audio system. Capable of passing 4K 60Hz with scaling, the EVSP24VW is the perfect video wall solutions for small and large applications.
Main Features
- 4K 2×4 HDMI Video Wall Processor
- Allows for 16 rows and columns of displays in any video wall configuration up to 16×16
- Two HDMI loop-outs to cascade into other units for larger video walls or to monitor sources locally
- Two HDMI inputs allow for multiple source video wall configurations, or to switch one source across the entire video wall display
- Passes up to 4K 60Hz with HDR
- Able to scale output resolutions
- HDMI 2.0 and HDCP 2.2 compliant
- Customizable options for bezel adjustment
- Supports 180° screen rotation
- Able to be controlled over RS232 and TCP/IP via product software or 3rd party control systems
General Information
Name: Evolution EVSP24VW Evolution Expandable 4k 2x4 HDMI Video Wall Processor
Category: Evolution by Vanco, Pro AV, Commercial Audio, Pro Audio Processors
UPC Code: 741835115216
Country of Origin: China. Country of origin is subject to change.
Specifications
-
ADI Part Number ZX-EVSP24VW Brand Name Vanco Manufacturer Vanco International, Inc Manufacturer Part Number EVSP24VW Product Line Evolution Product Model EVSP24VW Product Name Expandable 4K 2×4 HDMI Video Wall Processor Product Type HDMI Splitter
-
USB Yes
-
Network (RJ-45) Yes Number of Network (RJ-45) Ports 1 USB Yes
-
Depth 5.7" Depth (mm) 144.78 Height 1.7" Height (mm) 43.18 Width 8.5" Width (mm) 215.9
-
Environmental Certification WEEE Environmentally Friendly Yes Package Contents - Expandable 4K 2×4 HDMI Video Wall Processor
- 2×4 Video Wall Processor
- 5-pin Phoenix Connector
- 2 x 3-pin Phoenix Connector
- RS232-Phoenix Connector Adapter Cable
- and more below
