Product Overview
Create a reliable point-to-point (PtP) connection between networks at distances of up to 9.3 miles with the airFiber 60 Xtreme-Range Wireless Bridge from Ubiquiti Networks. This 60 GHz outdoor bridge is designed to provide low-interference, low-latency, and high-throughput connectivity with up to 5.4 Gb/s (2.7 Gb/s duplex) throughput. An integrated 5 GHz backup radio provides over 800 Mb/s transfer speeds. You can power the network bridge by connecting the Gigabit Ethernet uplink port to the included PoE injector or a compatible switch to transfer data and power over a single cable. A 10G SFP+ port is also available for high-speed fiber connections. Made from UV-stabilized plastic and steel with an IPX6 rating, the airFiber 60 Xtreme-Range can operate at temperatures between -40 and 131 degF. A precision alignment pole mount is included for easy placement. Other features include integrated GPS, WPA2-PSK signal encryption, and Bluetooth management through the Ubiquiti Internet Service Provider (UISP) application
General Information
Name : Ubiquiti AF60-XR-US AirFiber Xtreme Range 15km+ 60 GHz Radio, US , Ubiquiti
Category : Network Bridges
UPC Code : 810010076069
Country of Origin : +1. Country of origin is subject to change.
Specifications
General Information
ADI Part Number : KX-AF60XRUS
Brand Name : Ubiquiti
Manufacturer : Ubiquiti Inc.
Manufacturer Part Number : AF60-XR-US
Product Model : AF60-XR-US
Product Name : Ubiquiti Networks airFiber 60 Xtreme-Range Wireless Bridge
Product Series : AF
Product Type : Wireless Bridge
Weight (Approximate) (g) : 13018.101
Technical Information
Bluetooth Standard : Yes
Indoor Antenna Range : 15 km
Indoor Antenna Range (mm) : 15000000
Power Consumption : 22-54V DC
Wireless LAN Standard : AirFiber
Interfaces/Ports
Number of Network (RJ-45) Ports : 2
Network & Communication
Ethernet Technology : 1 Gigabit
Physical Characteristics
Antenna Form Factor : Internal
Depth : 15.1"
Depth (mm) : 383.54
Form Factor : Pole Mount
Height : 30.7"
Height (mm) : 779.78
Weight (Approximate) : 28.7 lb
Width : 26.1"
Width (mm) : 662.94
Power Description
Plug/Connector Type : Wireless
Power Consumption (A) : 0.65
Power Consumption (W) : 24
Tuner
Frequency Band : 71 GHz
Frequency Band (Hz) : 71000000000
Miscellaneous
Environmental Certification : CE, FCC, IC
Environmentally Friendly : Yes
