Product Overview
HD+ IR indoor dome cameras allow users to upgrade their surveillance systems to HD using legacy coax cabling without the costly process of ripping and replacing coax with Ethernet cabling. The HD+ cameras offer a variety of high-performance features including Day/Night operation, motion detection, defog, IR illuminators and more depending on model. Setup functions are easily controlled by OSD with the built-in joystick or control over coaxial cable with HD+ DVRs. Low power consumption, compact form factors, and transmission up to 1,640 feet further enhance the lineup.
General Information
Name : Hanwha SCD-6085R 2MP Analog IR Dome Camera, 3.2-10mm Varifocal Lens , Hanwha Vision
Category : Dome Cameras
UPC Code : 8801089180261
Country of Origin : Vietnam. Country of origin is subject to change.
Specifications
General Information
ADI Part Number : SQ-SCD6085R
Brand Name : Hanwha Vision
Connectivity Technology : Wired
Manufacturer : Hanwha Group
Manufacturer Part Number : SCD-6085R
NDAA Compliant : yes
Product Model : SCD-6085R
Product Name : 2MP Analog IR Dome Camera
Product Series : AHD
Product Type : Surveillance Camera
Weight (Approximate) (g) : 320
Technical Information
Effective Camera Resolution : 2MP
Field of View : H : 110.2°(Wide) ~ 32°(Tele) V : 55.4°(Wide) ~ 18°(Tele) D : 128.4°(Wide) ~ 36.6°(Tele)
HD Recording : Yes
Lens Type : Varifocal
Maximum Aperture : f/1.6
Maximum Focal Length (mm) : 10
Maximum Frame Rate : 30 fps
Minimum Focal Length : 3.2 mm
Night Vision : Yes
Night Vision Type : Color
Optical Zoom : 3.1x
Camera
Night Vision Distance : 65.62 ft
Night Vision Distance (mm) : 20000
Display & Graphics
Color Supported : Color, Monochrome
Effective Camera Resolution (Pixel) : 2000000
Maximum Video Resolution : 1920 x 1080
Minimum Illumination (lux) : 0.11
Environmental Conditions
Maximum Operating Temperature : 131°F (55°C)
Maximum Operating Temperature (°F) : 131
Minimum Operating Temperature : 14°F (-10°C)
Minimum Operating Temperature (°F) : 14
Operating Humidity : 90%
Exposure
Longest Shutter Speed : 1 Second
Minimum Illumination : 0.1 lux
Shortest Shutter Speed : 1/12000 Second
Lens
Focal Length : 3.2-10 mm
Lens Included : Yes
Maximum Focal Length : 10 mm
Physical Characteristics
Color : White
Depth : 4.7"
Diameter (mm) : 119.8
Form Factor : Dome
Weight (Approximate) : 11.29 oz
Width : 4.7"
Power Description
Input Voltage : 12V DC, 24V AC
Input Voltage (V AC) : 24
Input Voltage (V DC) : 12
Product Information
Diameter : 4.7"
Mount Type : Backbox Mount, Corner Mount, Flush Mount, Gooseneck, Hanging Mount, In-ceiling, Parapet Mount, Pendant Mount, Pole Mount, Wall Mount
Projection Lens
Minimum Focal Length (mm) : 3.2
Storage
Recording Formats : HD
Video
Analog Video Signal Format : AHD, CVBS
Maximum Frame Rate (fps) : 30
Miscellaneous
Features : Alarm Triggering, Back Light Compensation (BLC), Built-in Mechanical ICR, Day/Night, Defog, Digital Noise Reduction, Digital Wide Dynamic Range (D-WDR), Gain Control, Highlight Compensation (HLC), Motion detection, Privacy Masking, White Balance
Indoor/Outdoor : Indoor
