Product Overview
AXIS P1378-LE Network Camera offers clear, sharp images in any day or night scene. This robust, fixed box camera acts as a deterrent and is ideal for surveillance in wide, outdoor areas where a high level of detail is needed, such as at airports, cargo areas and public transportation systems.
With excellent 4K resolution, AXIS P1378-LE captures detailed images of fast-moving objects and people. Thanks to Axis Zipstream with support for H.264/H.265, the camera provides exceptional savings on bandwidth and storage requirements without compromising image quality. It offers scene profiles, corridor format and electronic image stabilization for stable images in situations where the camera is subject to vibrations. The camera is ideal for varous surveillance situations thanks to a CS mount and support for motorized i-CS lenses, enabling remote zoom. Use our lens calculator to select a lens that meets your specific requirements.
General Information
Name : AXIS P1378-LE P13 Series 4K Outdoor IR Barebone Box IP Camera, Lens Not Included, White , AXIS Communications
Category : Box Cameras
UPC Code : 7331021069657
Country of Origin : Thailand. Country of origin is subject to change.
Specifications
General Information
ADI Part Number : Z4-01811031
Brand Name : AXIS, Axis Communications
Connectivity Technology : Wired
Manufacturer : Axis Communications
Manufacturer Part Number : 01811-031
NDAA Compliant : Yes
Product Model : P1378-LE
Product Name : P1378-LE Network Camera
Product Series : P13
Product Type : Network Camera
Weight (Approximate) (g) : 2400
Technical Information
Field of View : With IK10 protection in front window - Horizontal field of view: 115°-45° - Vertical field of view: 61°-25° - Without IK10 protection in front window - Horizontal field of view: 119°-45° - Vertical field of view: 62°-25°
HD Recording : Yes
Lens Mount Type : CS Mount
Lens Type : Varifocal
Maximum Aperture : f/1.5
Maximum Focal Length (mm) : 10
Maximum Frame Rate : 30 fps
Minimum Focal Length : 3.9 mm
Optical Zoom : 2.6x
Video Formats : H.264, H.265, MJPEG, MPEG-4
Camera
Image Sensor Type : CMOS
Display & Graphics
Color Supported : Color
Maximum Video Resolution : 3840 x 2160
Minimum Illumination (lux) : 0.03
Environmental Conditions
Maximum Operating Temperature : 140°F (60°C)
Maximum Operating Temperature (°F) : 140
Minimum Operating Temperature : -40°F (-40°C)
Minimum Operating Temperature (°F) : -40
Operating Humidity : 100%
Exposure
Longest Shutter Speed : 1/5 Second
Minimum Illumination : 0 lux
Shortest Shutter Speed : 1/8500 Second
Interfaces/Ports
Network (RJ-45) : Yes
Lens
Lens Included : No
Maximum Focal Length : 10 mm
Network & Communication
Remote Management : Yes
Physical Characteristics
Color : White
Durability : Dust Resistant, Impact Resistant, Vandal Resistant, Water Resistant, Weather Resistant
Form Factor : Box
Weight (Approximate) : 5.29 lb
Power Description
Input Voltage : 28 V DC
Input Voltage (V DC) : 28
Product Information
Mount Type : Backbox Mount, Bracket Mount, Ceiling Mount, Column Mount, Conduit Mount, Corner Mount, Pole Mount, Wall Mount
Projection Lens
Minimum Focal Length (mm) : 3.9
Storage
Recording Formats : 4K
Storage Type : Memory Card
Video
Maximum Frame Rate (fps) : 30
Warranty
Limited Warranty : 5 Year
Miscellaneous
Features : Active Tampering Alarm, Audio Detection, Auto Gain Control, Built-in Infrared Illuminator, Built-in IR LED, Cross Line Detection, Day/Night, Defog, Electronic Image Stabilization, HTTPS Encryption, Microphone In, Motion Detection, Password Protection, Privacy Masking, PTZ, Removable IR Cut-off Filter, SD Card Local Storage, Shock Detection, Tampering Alarm, White Balance, Wide Dynamic Range
Impact Protection Rating : IK10
Indoor/Outdoor : Outdoor
Ingress Protection Rating : IP66, IP67
Package Contents : <ul> <li>P1378-LE Network Camera</li> <li>Installation Guide</li> <li>Windows Decoder 1-user License</li> <li>Wall Mount Bracket</li> <li>Sunshield</li> <li>Connector Kit</li> </ul>
TAA Compliant : Yes
