Product Overview
This Thunderbolt 4 USB-C Cable brings lightning-speed data transfers, 4K video support, and power delivery up to 100W. Get more done with less hassle by carrying one cable for the simplest, most reliable, and fastest connectivity for video, data, and power.
Deliver up to 40Gbps to or from a Thunderbolt 3 or Thunderbolt 4 enabled port. This cable is an ideal solution to transfer large amounts of information, whether uploading or downloading data. It is so fast you can transfer a 5GB file in about a second over the cable.
Stream video and audio with full DisplayPort 2.1 and 'Alt' mode functionality, displaying up to 8K video on a single display or 4K video on two displays for low-latency gaming, immersive creation, and simplified productivity with fantastic contrast and color depth to see photos, videos, and text with unbelievable detail.
Deliver up to 100W of charging power to or from the connected device, like your phone, laptop, or tablet, and other compatible USB devices to charge them quickly.
Connect to a high-speed 10 Gigabit Ethernet network or connect two computers over a peer-to-peer network, allowing for the transfer of large volumes of data from one PC to another, which is ideal when upgrading to a new system.
Connect with confidence, knowing that this Thunderbolt 4 cable has been certified and tested to ensure broad compatibility across Mac®, Windows®, and Chrome OS™ devices.
Additional Technical Specs
Signal Specifications
- Resolutions up to 4K (4096 x 2160) at 60Hz
- Signal Bandwidth: 40Gbps Bidirectional
Electrical Specifications
- Voltage Rating: 30V
- Temp Rating: 80°C
- Max Conductor Resistance at 20°C (OHMS/KM): 30AWG: 387; 32AWG: 588
- Insulation Resistance at 20°C (min): DC-500V 100 KOHM/KM
- Dielectric Strength (min): AC-750V/1 Sec.
Physical Specifications
- Operating Temperature: 0°C to 50°C; Ambient (Non-Condensing)
- Storage Temperature: 0°C to 70°C; Ambient (Non-Condensing)
- Operating Temperature (C2G28887 only): -20°C to 85°C; Ambient (Non-Condensing)
- Storage Temperature (C2G28887 only): 0°C to 40°C; Ambient (Non-Condensing)
- Minimum Bend Radius: 48mm
General Information
Name : C2G C2G28887 6' Thunderbolt Active Cable USB to USB 40Gbps, Black , C2G by Legrand
Category : Pro USB Cables
UPC Code :
Specifications
General Information
ADI Part Number : 2D-C2G28887
Brand Name : C2G by Legrand
Manufacturer : Legrand Group
Manufacturer Part Number : C2G28887
Product Name : 6ft (2m) Thunderbolt 4 USB-C Active Cable (40Gbps)
Product Type : Data Transfer Cable
Technical Information
American Wire Gauge : 42AWG
Cable Type : USB-C
Device Supported : Notebook, Phone, Tablet, USB Device
Shielding : Yes
Supported Resolution : 4096 x 2160|1080
Media & Performance
Data Transfer Rate : 40 Gbit/s
Data Transfer Rate (Bps) : 5368709120
Physical Characteristics
Cable Length : 6'
Cable Length (mm) : 1828.8
Color : Black
Miscellaneous
Environmental Certification : EU RoHS
Environmentally Friendly : Yes
Features : Active, Bendable, Charging, DisplayPort Alternate (ALT) Mode, Sync-N-Go Technology
TAA Compliant : No
