C2G C2G30013 4K 60 Hz HDMI HDBaseT 3.5mm, USB-B to A, and RS232 Over CAT Extender Box Transmitter to Box Receiver
C2G30013 | 2D-C2G30013
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
The HDMI HDBaseT + 3.5mm, USB-B to A, and RS232 over Cat Extender Box Transmitter to Box Receiver - 4k 60hz allows a 4K HDMI source to be extended up to 130ft to a 4K display using a single Cat6a Ethernet cable. This is an ideal solution where USB must be extended alongside HDMI video and audio to interactive whiteboards and displays in conference rooms, classrooms, lecture halls, and many other installation needs that are far beyond the length limitations of standard HDMI cabling.
Main Features
- Extend 4K at 60Hz (4:2:0) up to 130' and 1080p at 60Hz up to 230' with Cat 6a cable
- Extend 4K at 60Hz (4:2:0) up to 115' and 1080p at 60Hz up to 200' with Cat 5e/6 cable
- Supports USB 2.0 pass through over HDBT up to 230' connecting up to 4 USB devices to the receiver
- HDCP 2.2 compliant, to create a secure connection between the source and display
- Supports CEC switch command sent by wall-plate
- One-way analog audio pass through from wall-plate transmitter to receiver
- One-way Power over HDBaseT (PoH), so that the wall plate can be powered by receiver
- HDBaseT Chipset VS210, for simpler HDBaseT installations
General Information
Name: C2G C2G30013 4K 60 Hz HDMI HDBaseT 3.5mm, USB-B to A, and RS232 Over CAT Extender Box Transmitter to Box Receiver
Category: C2G by Legrand, Pro AV, Commercial Connector Cables, Pro HDMI Cables
UPC Code: 757120300137
Country of Origin: China. Country of origin is subject to change.
Specifications
ADI Part Number 2D-C2G30013 Brand Name C2G by Legrand Country of Origin CN Manufacturer Legrand Group Manufacturer Part Number C2G30013 Packaged Quantity 305 Product Name Video Extender Transmitter/Receiver Product Type Video Extender Transmitter/Receiver
Cable Type Category 6 Conductor Count 8 Connectivity Technology Wired Media Type Supported Twisted Pair Number of Conductors 8 Number of Input Devices Supported 1 Number of Output Devices Supported 1 Number of Pairs 4
NDAA Compliant Yes TAA Compliant No
Network (RJ-45) Yes Number of HDMI Inputs 1 Number of HDMI Outputs 1 Number of Network (RJ-45) Ports 2 Number of USB Ports 5
Form Factor Wall Plate
Graphics Mode 4K UHD Graphics Modes 4K UHD
Environmental Certification REACH, ROHS, Prop 65, TSCA, NDAA 889
