APC SMT3000RM2U 3000VA Smart-UPS, Line Interactive, Rackmount, 2U, 120V
SMT3000RM2U
|2G-SMT3000RM
Shop all APC by Schneider Electric
APC SMT3000RM2U 3000VA Smart-UPS, Line Interactive, Rackmount, 2U, 120V
SMT3000RM2U | 2G-SMT3000RM
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
Main Features
- Adjustable voltage sensitivity - Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications.
- Adjustable voltage-transfer points - Maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation.
- Audible alarms - Provides notification of changing utility power and UPS power conditions
- Automatic restart of loads after UPS shutdown - Automatically starts up the connected equipment upon the return of utility power.
- Automatic self-test - Periodic battery self-test ensures early detection of a battery that needs to be replaced.
- Battery failure notification - Provides early-warning fault analysis on batteries enabling timely preventive maintenance
- Boost and Trim Automatic Voltage Regulation (AVR) - Gives higher application availability by correcting low and high voltage conditions without using the battery (not available on all models).
- Disconnected battery notification - Warns when a battery is not available to provide backup power.
- Energy meter - Provides actual kilowatt hours of usage for energy conscious users.
- Green mode - Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.
General Information
Name: APC SMT3000RM2U 3000VA Smart-UPS, Line Interactive, Rackmount, 2U, 120V
Category: APC by Schneider Electric, Batteries & Power Supplies, Power Management, UPS
UPC Code: 731304279549
Country of Origin: Philippines. Country of origin is subject to change.
Specifications
ADI Part Number 2G-SMT3000RM Brand Name APC by Schneider Electric Manufacturer Schneider Electric SA Manufacturer Part Number SMT3000RM2U Product Line Smart-UPS Product Model SMT3000RM2U Product Name Smart-UPS SMT3000RM2U 3000VA Rack-mountable UPS Product Type Line-interactive UPS
Backup/Run Time (Full Load) 3-Minute Backup/Run Time (Half Load) 12-Minute Hot Swappable Yes Number of Battery & Surge Outlets 8 Output Voltage 120V AC Receptacle Detail 2 x NEMA 5-20R, 6 x NEMA 5-15R Receptacle Type NEMA 5-15R, NEMA 5-20R
Battery Characteristics Maintenance-free, Sealed, Spill-proof Battery Chemistry Lead Acid Battery Recharge Time 3-Hour Maximum Storage Relative Humidity 0.95
Energy Star Yes
Serial Port Yes
Color Green Depth 26.9" Form Factor Rack Mount Height 3.4" Rack Height 2U Weight 97.42lb Width 18.9"
Input Voltage 120V AC Plug/Connector Type NEMA L5-30P Waveform Type Sine Wave
Mount Type Rack Mount
Limited Warranty 3-Year
Country of Origin PH Environmentally Friendly Yes Package Contents - Smart-UPS SMT3000RM2U 3000VA Rack-mountable UPS
- CD with software
- Documentation CD
- Installation guide
- Rack mounting hardware
- Rack mounting support rails
- and more below
