Prysmian 7151870 CAT6a GS10 Unshielded Twisted Pair CMP Cable, 1000' (304.8m), White

7151870 | 2M-7151870

Please sign in to view pricing, availability, and to add to cart.

Overview

Specifications

Documents

Product Overview

Main Features

Smaller cable diameter allows for greater cable density, reducingcable management costs.
Simplified design and improved bend radius make it easIer to strip,terminate and route, reducing installation time and expense.
UL Listed CMP-LP 0.7A with certified performance for high-power PoE applications.
CMP - UL verified with certified performance for 100W power over HDBaseT.
CMP 105°C jacket rating provides greater protection against increased operating temperatures and for high-wattage applications.
TRU-Mark print legend contains footage markings from 1000' to 0'
All GenSPEED products are made in the U.S.A. Applications
IEEE 802.3: 10G BASE-T, 1000 BASE-T, 100 BASE-TX, 10 BASE-T,PoE, PoE+ and PoE++
ANSI/TIA 854: 1000 BASE-TX
CDDI, Token Ring, ATM

General Information

Name: Prysmian 7151870 CAT6a GS10 Unshielded Twisted Pair CMP Cable, 1000' (304.8m), White

Category: Prysmian Group, Wire & Cable, Network Cables, Category 6A Network Cables

UPC Code: 079407681358

Country of Origin: . Country of origin is subject to change.

Specifications

: ADI Part Number 2M-7151870 Brand Name Prysmian Group Manufacturer Prysmian Group Manufacturer Part Number 7151870 Product Model 7151870 Product Name 23-4P UTP-CMP SOL BC CAT6A LS/FRPVC White JKT RL-IN-BX GS10 UTP GEN5 .23OD Product Type Telecom Cable

: American Wire Gauge 23AWG Cable Rating Plenum Cable Type Category 6a Conductor Material Copper Jacket Material PVC Number of Pairs 4-Pair Shielding No Solid or Stranded Solid

: Cable Length 1000' Color White Insulation Material FEP Package Type Reel Weight 30lb

: Voltage Rating 300V

: Installation Type Commercial, Residential

: Certifications & Standards RoHS

Documents and Resources

Download All Documents

Product Data Sheet

Manufacturer Brochure
