Digital Watchdog DWC-MB75WI4TW MEGApix IVA 5MP IP Bullet Camera, 4mm Fixed Lens, White
DWC-MB75WI4TW|6K-MB75WI4TW
Digital Watchdog DWC-MB75WI4TW MEGApix IVA 5MP IP Bullet Camera, 4mm Fixed Lens, White
DWC-MB75WI4TW|6K-MB75WI4TW
Key Features
- 5MP sensor at real-time 30fps
- Star-Light Plus color in near-total darkness technology
- Intelligent Video Analytics (IVA) with extended features (IVA+)
Key Features
- 5MP sensor at real-time 30fps
- Star-Light Plus color in near-total darkness technology
- Intelligent Video Analytics (IVA) with extended features (IVA+)
Sign In for Dealer Pricing
Become an ADI CustomerKey Features
- 5MP sensor at real-time 30fps
- Star-Light Plus color in near-total darkness technology
- Intelligent Video Analytics (IVA) with extended features (IVA+)

Digital Watchdog
Digital Watchdog DWC-MB75WI4TW MEGApix IVA 5MP IP Bullet Camera, 4mm Fixed Lens, White
DWC-MB75WI4TW | 6K-MB75WI4TW
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
This MEGApix IP camera is your gateway to powerful video analytics features. Provides 5MP resolution at real-time 30fps. This camera includes a 4.0mm fixed lens, simultaneous H.265/H.264/MJPEG codec support and Star-Light Plus color in near-total darkness technology for quality video in any lighting condition, all in an IP67 dust-tight and waterproof bullet housing.
Main Features
- 5MP sensor at real-time 30fps
- Star-Light Plus color in near-total darkness technology
- Intelligent Video Analytics (IVA) with extended features (IVA+)
- Seamless integration and control of IVA rules with DW Spectrum IPVMS
- Reduce false alarms
- Increase your recording storage with logic rules and smart recording
- 4.0mm fixed lens
- True Wide Dynamic Range (WDR) for clear images in challenging light
- Simultaneous streaming and multiple codec options for smart bandwidth management
- 100' Smart IR with intelligent camera sync for clear B/W images with no need for external light
General Information
Name: Digital Watchdog DWC-MB75WI4TW MEGApix IVA 5MP IP Bullet Camera, 4mm Fixed Lens, White
Category: Digital Watchdog, Video Surveillance, IP Cameras, Bullet Cameras
UPC Code: 812226037179
Country of Origin: Vietnam. Country of origin is subject to change.
Specifications
-
ADI Part Number 6K-MB75WI4TW Brand Name Digital Watchdog Manufacturer Digital Watchdog Manufacturer Part Number DWCMB75WI4TW Product Line MEGApix Product Model DWC-MB75WI4TW Product Name MEGApix 5MP bullet IP camera with fixed lens and IR Product Series MB75 Product Type Network Camera Supported Network Protocols IPv4 Weight 1.01lb
-
American Wire Gauge 18AWG Connectivity Technology Wired Effective Camera Resolution 5MP Field of View Horizontal, Vertical Illumination Distance 100' Lens Type Fixed Maximum Frame Rate 30fps Minimum Focal Length 4mm Motion Detection Yes Night Vision Yes Night Vision Type Infrared Output Voltage 12V DC Programmable Yes Protocols Bonjour, DDNS, DHCP, DNS, Genetec Protocol, HTTP, HTTPs, IGMP, NTP, RTP, RTP (UDP/TCP), RTSP, SNMP, SNMPv1/v2/v3 (MIB-2), TCP, Telnet, UPnP, Zeroconf (AutoIP) Video Formats H.264, MJPEG
-
Memory Card Slot Yes
-
Image Sensor Type CMOS Night Vision Distance 100 ft Wide Dynamic Range Yes
-
Ingress Protection Rating IP67
-
Image Sensor Size 1/2.8" Maximum Video Resolution 3008 x 3000
-
Maximum Operating Temperature 122°F (50°C) Minimum Operating Temperature -4°F (-20°C) Operating Humidity 10-90% (Non-condensing) Operating Temperature (T-T) -4-122°F
-
Longest Shutter Speed 8 Second Minimum Illumination 0.0 lux (B/W)|0.16 lux (color) Shortest Shutter Speed Off|x15|x2|x3|x4|x5|x6|x7.5
-
Aspect Ratio 4:3
-
Focal Length 4.0 mm Focus Modes Auto, Manual Lens Included Yes Maximum Focal Length 4 mm
-
Remote Management Yes
-
ADI Part Number Replaces 6K-MB75WI4T Model Number Replaces DWC-MB75WI4T
-
Color White Durability Dust Resistant, Waterproof, Weather Resistant Form Factor Bullet Height 6.1" Material Aluminum Die-cast Width 5.9"
-
Input Voltage 12V DC
-
Mount Type Ceiling Mount, Wall Mount
-
Storage Type Memory Card
-
Amperage 541.6mA
-
Analog Video Signal Format CVBS Maximum Resolution 1280 x 720
-
Limited Warranty 5-Year
-
Certifications CE, FCC, NDAA, UL Listing Country of Origin VN Environmental Certification RoHS Environmentally Friendly Yes Features 3D Digital Noise Reduction, Alarm Detection, Auto Flip, Auto Gain Control, Built-in Web Server, Cross Line Detection, Day/Night, Defog, Enter/Exit Detector, Mirror, Motion Detection, SD Card Local Storage, Smart IR, Tamper Detection, Wide Dynamic Range
