Belden 10GX53F 0091000 10GX CAT6A Enhanced Cable, 4-Pair, F/UTP, CMP, 1000', White
10GX53F 0091000
|7B-10GX53F9
Shop All Belden
Belden 10GX53F 0091000 10GX CAT6A Enhanced Cable, 4-Pair, F/UTP, CMP, 1000', White
10GX53F 0091000 | 7B-10GX53F9
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
10GX Category 6A Enhanced Premise Horizontal Cable (625MHz), 4 Pair, 23 AWG Solid Bare Copper Conductors, F/UTP - Foil Shielded, Plenum-CMP, Flamarrest PVC-LS Jacket.
Main Features
- 23 AWG, Solid, BC - Bare Copper
- 4 pairs
- Flamarrest
- FEP - Fluorinated Ethylene Propylene Insulation
- 300 V (CMP), 300 V (CL3P)
- 25 lbs (11 kg) Max. Pull Tension
- Plenum, Indoor
- CMP
- Category 6A
- Suitable Applications: Premise Horizontal Cable, Ethernet up to 10GBASE-T, Wi-Fi 6, Wi-Fi 5, Surveillance, HDBaseT, PoE++, PoE+, PoE, Noisy Environments
General Information
Name: Belden 10GX53F 0091000 10GX CAT6A Enhanced Cable, 4-Pair, F/UTP, CMP, 1000', White
Category: Belden, Wire & Cable, Network Cables, Category 6A Network Cables
UPC Code: 612825377788
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number 7B-10GX53F9 Brand Name Belden Manufacturer Part Number 10GX53F 0091000 Packaged Quantity 305
American Wire Gauge 23AWG Application/Usage Ethernet up to 10GBASE-T, HDBaseT, Noisy Environments, PoE, PoE+, PoE++, Premise Horizontal Cable, Surveillance, Wi-Fi 5, Wi-Fi 6 Cable Rating Plenum Cable Type Category 6a Conductor Count 8 Conductor Material Bare Copper Jacket Material PVC Jacket Type CMP Number of Conductors 8 Number of Pairs 4 Shielding Foil Solid or Stranded Solid
Operating Temperature (T-T) -20-75°C Storage Temperature (T-T) -20-75°C
Cable Length 1000' Color White Insulation Material FEP
Country of Origin MX Environmental Certification REACH, RoHS, WEEE Environmentally Friendly Yes Indoor/Outdoor Indoor
