Belden 1694A 0061000 75 Ohms SDI Coax, RG-6, 18 AWG Solid BC Conductor, PE Insulation, Foil 95% Tinned Copper Braid Shield, PVC Jacket, CMR, Blue
1694A 0061000
|7B-1694100BL
Shop all Belden
Belden 1694A 0061000 75 Ohms SDI Coax, RG-6, 18 AWG Solid BC Conductor, PE Insulation, Foil 95% Tinned Copper Braid Shield, PVC Jacket, CMR, Blue
1694A 0061000 | 7B-1694100BL
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
The Belden 1694A 0061000 is an SDI coaxial cable designed for digital video transmission with 75 Ohms impedance. It features an 18 AWG solid bare copper conductor and PE insulation to maintain signal integrity. The cable includes a foil shield with 95% tinned copper braid for effective interference protection and a blue PVC jacket rated CMR for riser use. Available in a 1,000-foot length, this RG-6 cable supports professional video applications requiring high-quality transmission.
Main Features
- 75 Ohms impedance
- Supports SDI digital video
- RG-6 coaxial cable type
- 18 AWG solid BC conductor
- PE insulation
- Foil with 95% tinned copper braid shield
- PVC jacket
- CMR rated for riser applications
- 1000'
General Information
Name: Belden 1694A 0061000 75 Ohms SDI Coax, RG-6, 18 AWG Solid BC Conductor, PE Insulation, Foil 95% Tinned Copper Braid Shield, PVC Jacket, CMR, Blue
Category: Belden, Wire & Cable, Coaxial Cables
UPC Code: 612825358220
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number 7B-1694100BL Brand Name Belden Manufacturer Part Number 1694A 0061000
American Wire Gauge 18AWG Application/Usage 6 Gb/s UHDTV, Digital Video, HD-SDI 1080p Cable Type Coaxial Conductor Count 1 Conductor Material Bare Copper Impedance 75 ohms Jacket Material PVC Number of Conductors 1 Shielding Yes Solid or Stranded Solid
Operating Temperature (T-T) -30-75°C
Cable Length 1000' Color Light Blue Insulation Material PO Package Type Reel
Length 1000'
Limited Warranty 10-Year
Country of Origin MX Indoor/Outdoor Indoor, Outdoor
