Belden 10GXS13 0051000 CAT6A 4-Pair Unshielded Twisted Pair CMP Cable, Dark Green
10GXS13 0051000
|7B-1GXS1351
Shop All Belden
Belden 10GXS13 0051000 CAT6A 4-Pair Unshielded Twisted Pair CMP Cable, Dark Green
10GXS13 0051000 | 7B-1GXS1351
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
10GXS Category 6A Enhanced Premise Horizontal Cable (625MHz), 4 Pair, 23 AWG Solid Bare Copper Conductors, U/UTP, Plenum-CMP, Flamarrest PVC-LS Jacket.
Main Features
- Category 6A Enhanced Premise Horizontal Cable supporting 625MHz bandwidth
- 4 pairs of 23 AWG solid bare copper conductors
- Unshielded Twisted Pair (U/UTP) configuration
- Plenum-rated CMP jacket for flame retardant properties
- Flamarrest PVC-LS outer jacket
- Cable color is Dark Green
General Information
Name: Belden 10GXS13 0051000 CAT6A 4-Pair Unshielded Twisted Pair CMP Cable, Dark Green
Category: Belden, Wire & Cable, Network Cables, Category 6A Network Cables
UPC Code: 612825003991
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number 7B-1GXS1351 Brand Name Belden Manufacturer Part Number 10GXS13 0051000 Packaged Quantity 305
American Wire Gauge 23AWG Application/Usage 10 Gigabit Ethernet, 100BaseTX, 100BaseVG ANYLAN, 155ATM, 622ATM, AES/EBU Digital Audio, AES51, Noisy Environments, NTSC/PAL Component or Composite Video, PoE, PoE Plus, Premise Horizontal Cable, RS-422, WIFI, Wireless Cable Rating Plenum Cable Type Category 6a Conductor Count 8 Conductor Material Bare Copper Jacket Material PVC Number of Conductors 8 Number of Pairs 4 Shielding No Solid or Stranded Solid
Operating Temperature (T-T) -20-75°C Storage Temperature (T-T) -20-75°C
Cable Length 1000' Color Green Insulation Material FEP Package Type Reel
Country of Origin MX Indoor/Outdoor Indoor
