Belden 2412 005U1000 Category 6+ Enhanced Premise Horizontal Cable 350MHz, 4 Pair, 23 AWG Solid Bare Copper Conductors, U/UTP, Riser-CMR, PVC Jacket, Green, UnReel, 1,000'
2412 005U1000
|7B-24125U1
Shop All Belden
Belden 2412 005U1000 Category 6+ Enhanced Premise Horizontal Cable 350MHz, 4 Pair, 23 AWG Solid Bare Copper Conductors, U/UTP, Riser-CMR, PVC Jacket, Green, UnReel, 1,000'
2412 005U1000 | 7B-24125U1
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
Category 6 Enhanced Premise Horizontal Cable (350MHz), 4 Pair, 23 AWG Solid Bare Copper Conductors, U/UTP, Riser-CMR, PVC Jacket.
Main Features
- Category 6+ Enhanced Premise Horizontal Cable with 350MHz bandwidth
- 4 Pair, 23 AWG Solid Bare Copper Conductors
- U/UTP (Unshielded/Unshielded Twisted Pair) configuration
- Riser-CMR rated for vertical riser cable applications
- PVC Jacket for cable protection
- Green cable color for easy identification
- Available in 1,000-foot unreel length
General Information
Name: Belden 2412 005U1000 Category 6+ Enhanced Premise Horizontal Cable 350MHz, 4 Pair, 23 AWG Solid Bare Copper Conductors, U/UTP, Riser-CMR, PVC Jacket, Green, UnReel, 1,000'
Category: Belden, Wire & Cable, Network Cables, Category 6 Network Cables
UPC Code: 612825062127
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number 7B-24125U1 Application/Usage Ethernet 1000BASE-T, Ethernet 100BASE-TX, Ethernet 10BASE-T, PoE, PoE+, PoE++, Premise Horizontal Cable Manufacturer Part Number 2412 005U1000 Packaged Quantity 100
American Wire Gauge 23AWG Cable Rating Riser Cable Type Category 6 Conductor Material Bare Copper Fiber Category OS2 Jacket Type Standard Shielding No Solid or Stranded solid
Operating Temperature (T-T) -20-75°C Storage Temperature (T-T) -20-75°C
Cable Length 1000.00' Color Green Insulation Material PE, PO, PP Jacket Material PVC Material Bare Copper, PVC
Length 1000.00'
Indoor/Outdoor Indoor
