Belden 2413FS 009Z1000 Category 6+ Enhanced Cable 350MHz, 4 Pair, 23 AWG Solid Bare Copper Conductors, F/UTP - Foil Shielded, Plenum-CMP, Flamarrest PVC-LS Jacket, White, ReelTuff Box, 1,000'
2413FS 009Z1000
|7B-2413FS00V
Shop All Belden
Belden 2413FS 009Z1000 Category 6+ Enhanced Cable 350MHz, 4 Pair, 23 AWG Solid Bare Copper Conductors, F/UTP - Foil Shielded, Plenum-CMP, Flamarrest PVC-LS Jacket, White, ReelTuff Box, 1,000'
2413FS 009Z1000 | 7B-2413FS00V
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
Category 6 Enhanced Premise Horizontal Cable (350MHz), 4 Pair, 23 AWG Solid Bare Copper Conductors, F/UTP - Foil Shielded, Plenum-CMP, Flamarrest PVC-LS Jacket.
Main Features
- 4 Pair, 23 AWG Solid Bare Copper Conductors
- F/UTP - Foil Shielded
- Flamarrest PVC-LS Jacket
- FEP - Fluorinated Ethylene Propylene Insulation
- 350MHz
- 300 V (CMP)
- Plenum, Indoor
- NFPA 262, UL 910 (Plenum), FT6, IEC 60332-1-2
- Article 800, CMP, CL3P-LP (0.5A), CMP-LP (0.5A)
- Suitable Applications: Premise Horizontal Cable, Ethernet 1000BASE-T, Ethernet 100BASE-TX, Ethernet 10BASE-T, Surveillance, PoE++, PoE+, PoE, Noisy Environments
General Information
Name: Belden 2413FS 009Z1000 Category 6+ Enhanced Cable 350MHz, 4 Pair, 23 AWG Solid Bare Copper Conductors, F/UTP - Foil Shielded, Plenum-CMP, Flamarrest PVC-LS Jacket, White, ReelTuff Box, 1,000'
Category: Belden, Wire & Cable, Network Cables, Category 6 Network Cables
UPC Code: 612825489672
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number 7B-2413FS00V Application/Usage Ethernet 1000BASE-T, Ethernet 100BASE-TX, Ethernet 10BASE-T, Noisy Environments, PoE, PoE+, PoE++, Premise Horizontal Cable, Surveillance Brand Name Belden Country of Origin MX Manufacturer Part Number 2413FS 009Z1000 Package Type ReelTuff Box Packaged Quantity 305
American Wire Gauge 23AWG Cable Rating Plenum Cable Type Category 6 Conductor Count 8 Conductor Material Bare Copper Jacket Type CMP, Plenum Duplex Zip Number of Conductors 8 Number of Pairs 4 Shielding Yes Solid or Stranded Solid
Operating Temperature (T-T) -20-75°C Storage Temperature (T-T) -20-75°C
Cable Length 1000.00' Color White Insulation Material FEP Jacket Material PVC Material Bare Copper
Length 1000.00'
ADI Part Number Replaces 7B-2413F0090 Model Number Replaces 2413F 009Z500
Indoor/Outdoor Indoor
