Belden 9116SB 0101000 75 Ohm SDI Coax Cable, RG-6, 18 AWG Solid BCCS, Foil + 60% AL Braid, LSZH Jacket, CMG-LS, Black, 1000'
9116SB 0101000
|7B-911610SBK
Shop All Belden
Belden 9116SB 0101000 75 Ohm SDI Coax Cable, RG-6, 18 AWG Solid BCCS, Foil + 60% AL Braid, LSZH Jacket, CMG-LS, Black, 1000'
9116SB 0101000 | 7B-911610SBK
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
75 Ohm SDI Coax, RG-6, 18 AWG Solid Bare Copper Conductor Covered Steel, PE Insulation, Foil 60% Aluminum Braid Shield, LSZH Jacket, CMG-LS, Shipboard ABS Type Approved.
Main Features
- 75 Ohm SDI coax cable
- RG-6 size
- 18 AWG solid bare copper conductor covered steel
- Foil plus 60% aluminum braid shielding
- LSZH jacket
- CMG-LS rating
- Shipboard ABS type approved
- Length 1000'
General Information
Name: Belden 9116SB 0101000 75 Ohm SDI Coax Cable, RG-6, 18 AWG Solid BCCS, Foil + 60% AL Braid, LSZH Jacket, CMG-LS, Black, 1000'
Category: Belden, Wire & Cable, Coaxial Cables
UPC Code: 612825224532
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number 7B-911610SBK Brand Name Belden Manufacturer Part Number 9116SB 0101000 Packaged Quantity 305
American Wire Gauge 18AWG Application/Usage ABS approved for marine shipboard and offshore use, Digital Video, HD-SDI 1080p Conductor Count 1 Conductor Material Bare Copper Jacket Material LSZH Number of Conductors 1 Shielding Braid, Foil Solid or Stranded Solid
Operating Temperature (T-T) -20-75°C
Cable Length 1000' Color Black Insulation Material PE, PO, PP Package Type Reel
Limited Warranty 10-Year
Country of Origin MX Indoor/Outdoor Indoor, Outdoor
