Belden D6UP 010U1000 CAT6 23/4 Solid BC Premise Horizontal Cable, 250 MHz, U/UTP, Plenum-CMP, Flamarrest PVC-LS Jacket, 1000' UnReel, Black
D6UP 010U1000
|7B-D6UP010U1
Shop All Belden
Belden D6UP 010U1000 CAT6 23/4 Solid BC Premise Horizontal Cable, 250 MHz, U/UTP, Plenum-CMP, Flamarrest PVC-LS Jacket, 1000' UnReel, Black
D6UP 010U1000 | 7B-D6UP010U1
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
U/UTP, Category 6, 4-Pair, 24 AWG Stranded Bare Copper Conductors, Polyethylene Insulation, PVC Jacket, High Flexibility.
Main Features
- Category 6 cable with 4 pairs
- 23/4 solid bare copper conductors
- 250 MHz frequency rating
- U/UTP (Unshielded/Unshielded Twisted Pair) design
- Plenum CMP rating for fire safety
- Flamarrest PVC-LS jacket
- 1000' length on unreel
- High flexibility with polyethylene insulation
- 24 AWG stranded bare copper conductors
General Information
Name: Belden D6UP 010U1000 CAT6 23/4 Solid BC Premise Horizontal Cable, 250 MHz, U/UTP, Plenum-CMP, Flamarrest PVC-LS Jacket, 1000' UnReel, Black
Category: Belden, Wire & Cable, Network Cables, Category 6 Network Cables
UPC Code: 612825451457
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number 7B-D6UP010U1 Application/Usage Ethernet 1000BASE-T, Ethernet 100BASE-TX, Ethernet 10BASE-T, PoE, PoE+, PoE++, Premise Horizontal Cable, Surveillance Brand Name Belden Country of Origin MX Manufacturer Part Number D6UP 010U1000 Packaged Quantity 305
American Wire Gauge 23AWG Cable Rating Plenum Cable Type Category 6 Conductor Count 8 Conductor Material Bare Copper Number of Conductors 8 Number of Pairs 4 Shielding No Solid or Stranded solid
Operating Temperature (T-T) -20-75°C Storage Temperature (T-T) -20-75°C
Cable Length 1000.00' Color Black Jacket Material PVC
Length 1000.00'
Indoor/Outdoor Indoor
