Belden HI4D0060218LJ HI Distribution Network Tight Buffered Optical Multi-Mode 4 6 Fiber + 2 Copper #18
HI4D0060218LJ
|7B-H4D6218LJ
Shop All Belden
Belden HI4D0060218LJ HI Distribution Network Tight Buffered Optical Multi-Mode 4 6 Fiber + 2 Copper #18
HI4D0060218LJ | 7B-H4D6218LJ
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
FX Hybrid Indoor, OM4, Distribution, 6 Fibers, 02 x 18AWG, CMR-LS-OF, Sub-Unit 4.8mm (6F x 900UM), Erika Violet Jacket.
Main Features
- OM4 Fiber Optic Cable
- 6 Fibers for High Capacity
- 02 x 18AWG Power Conductors
- CMR-LS-OF Rated for Safety
- Erika Violet Jacket for Easy Identification
- Sub-Unit 4.8mm for Compact Design
General Information
Name: Belden HI4D0060218LJ HI Distribution Network Tight Buffered Optical Multi-Mode 4 6 Fiber + 2 Copper #18
Category: Belden, Wire & Cable, Fiber Optic Cables & Cords, Fiber Optic Cables
UPC Code:
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number 7B-H4D6218LJ Application/Usage Distributed Antenna Systems (DAS), Passive Optical Network (PON), Security (Cameras), Wireless Access Points (WAP) Brand Name Belden Manufacturer Part Number HI4D0060218LJ Product Name Indoor Hybrid Copper-Fiber Cable, OM4, 6 Distribution Fibers, #18-2c, CMR-OF Product Series FX Hybrid Product Type Copper-Fiber Cable
American Wire Gauge 18AWG Cable Type Hybrid Copper-Fiber Conductor Count 2 Conductor Material Tinned Copper Core/Cladding Diameter 50/125 µm Fiber Category OM4 Fiber Count 6 Fiber Optic Mode Multimode Number of Conductors 2 Number of Pairs 1 Solid or Stranded Stranded
Operating Temperature (T-T) -20-70°C Storage Temperature (T-T) -40-70°C
Color Pink Insulation Material PVC Jacket Material LSZH Material PVC Weight 68.00lb
Indoor/Outdoor Indoor
