Product Overview
D-Link DSS-200G-28MP supports 24 x 10/100/1000 Mbps PoE 4 x Combo 1 GB/SFP. 370w Power Budget The switch is designed specifically to meet the demands of surveillance applications of small, medium, and enterprise businesses. This innovative switch simplifies network setup and monitoring through its surveillance-focused interface and surveillance traffic optimization options, making the DSS-200G Series ideal for IP surveillance deployments. In addition, the switch includes 6KV Surge protection, PoE extend mode that can extend PoE reach to 250m and a range of diagnostic and troubleshooting tools providing a flexible solution for your surveillance requirements.
General Information
Name : D-Link DSS-200G-28MP 24-Port Gigabit Poe Smart Switch with Combo SFP Ports, 370W PoE Budget, 30W Max per PoE Port , D-Link
Category : Network Switches
UPC Code : 790069471803
Country of Origin : China. Country of origin is subject to change.
Specifications
General Information
ADI Part Number : 8E-200G28MP
Brand Name : D-Link
Manufacturer : D-Link Systems, Inc
Manufacturer Part Number : DSS-200G-28MP
NDAA Compliant : yes
Packaged Quantity : 1
Product Line : Industrial Switch
Product Model : DSS-200G-28MP
Product Name : 8-Port 10/100/1000 PoE Gigabit Ethernet Surveillance Switch
Product Series : DSS-200G
Product Type : Ethernet Switch
Weight (Approximate) (g) : 2860
Technical Information
Media Type Supported : Optical Fiber, Twisted Pair
Power Consumption : 425.90W
I/O Expansions
Number of Total Expansion Slots : 2
Interfaces/Ports
Port/Expansion Slot Details : 24 x Gigabit Ethernet PoE|4 x Gigabit Ethernet Combo
Total Number of Network Ports : 28
Media & Performance
Network Technology : 10/100/1000Base-T, 1000Base-X
Network & Communication
Ethernet Technology : Gigabit Ethernet
Layer Supported : 3
Networking Standards : IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
Physical Characteristics
Depth : 8.2"
Depth (mm) : 208
Form Factor : Rack mount
Height : 1.7"
Height (mm) : 44
Weight (Approximate) : 6.31 lb
Width : 17.3"
Width (mm) : 440
Power Description
Frequency : 50 Hz|60 Hz
Frequency (Hz) : 50, 60
Input Voltage : 120V AC, 230V AC
Input Voltage (V AC) : 120, 230
PoE (RJ-45) Port : Yes
PoE Budget : 370W
PoE Budget (W) : 370
Power Consumption (W) : 425.900
Power Source : Power Supply
Miscellaneous
TAA Compliant : no
