Product Overview
Designed for superior off-axis performance and easy installation, the RS62-EZ offers attractive styling in an economical speaker for open-ceiling uses. The RS62-EZ uses one 6.5 inch (165 mm) coaxial driver with BroadBeam Ring technology for consistently smooth high frequency sound and 16 ohm impedance for easy daisy chaining in low voltage systems. The RS62-EZ includes galvenized steel hanging cables and a built in mounting plate for suspending the speaker as well as a threaded opening on top of it's cover plate for direct-to-conduit mounting. The enclosure is constructed of injection molded ABS with glass fiber reinforcement for lasting durability in indoor or outdoor applications and includes an aluminum grille with protective powder coated finish. Cost effective engineering with high-performance sound makes the RS62-EZ speaker ideal for music and paging applications in retail, grocery stores, restaurants, hotels, casinos, museums, trade shows and conference rooms and is suitable for use in voice alarm applications subject to EU regulations EN60849 and BS5839-8. For applications where additional bass is required, SoundTube's RS1001i-II-T 10-inch subwoofer may be used. Hanging hardware, weather plug, cover plate, and AC-RSEZ-HH-10 are included.
General Information
Name: SoundTube RS62-EZ-BK 6.5" Hanging Speaker, Black
Category: SoundTube, Pro AV, Commercial Audio, Pro Speakers
UPC Code: 752830445987
Country of Origin: China. Country of origin is subject to change.
Specifications
ADI Part Number 9W-RS62EZBK Brand Name SoundTube Manufacturer Part Number RS62-EZ-BK
Maximum Frequency Response 22 kHz Minimum Frequency Response 100 Hz
ADI Part Number Replaces RI-RS62EZBK Model Number Replaces RS62-EZ-BK
Color Black Height 10.4" Width 10.08"
Environmental Certification CE, RoHS, UL Environmentally Friendly Yes Features Aluminum grille with protective powder-coated finish, Included accessories hanging hardware, weather plug, cover plate, Includes hanging hardware with galvanized steel cables and hanging bracket for fast, easy, and secure installation. Unit may be hung or mounted direct-to-conduit via locking cover plate, Unit ships in eco-friendly, recyclable packaging, Weatherized components for indoor and outdoor applications Package Contents Adapter, Cover Plate, Hanging Hardware, Weather Plug, Wire Gland
