AtlasIED IPS-ZC4 SIP-to-Analog 4-endpoint zone gateways are perfect for extending communication off network to create analog overhead paging systems for those environments where the SIP servers or VoIP communications managers may not support paging or where 3rd party notification applications are not required.ApplicationsAtlasIED IPS-ZC4 SIP-to-Analog gateways can register as SIP devices directly to a SIP server or VoIP communications manager and can provide up to 15 paging groups using its 4-zone outputs. When a caller dials a paging number, the IPS-ZC4 provides a one-way voice path to its analog outputs that have been designated to receive paging.When used within a Cisco Environment, this same SIP - to - Analog 4 endpoint zone gateway from AtlasIED can join Cisco's Unified Survivable Remote Site Telephony (SRST) as supported devices within SRST endpoint architecture. Cisco's SRST provides remote location callprocessing redundancy when access to the centralized Cisco Unified Communications Manager is interrupted because of a WAN outage. The ability to extend LAN communication between any combination of phones and speakers with visual notifications is particularly critical during an emergency,which may be the actual cause of the WAN outage.Ideal for Corporate Applications, Education Institutions, Entertainment Complexes, Industrial Facilities, Government Buildings, Healthcare Facilities, Houses of Worship, Transportation Hubs; anywhere the need for critical alerts/public address exists and a single enterprise-class communications platform is preferred
Name : AtlasIED IPS-ZC4 IP-to-Analog 4-Zone PoE Gateway for SIP Applications , AtlasIED
Category : Pro Accessories & Mounts
UPC Code : 612079661114
Country of Origin : Taiwan. Country of origin is subject to change.
ADI Part Number : AT-IPSZC4
Brand Name : AtlasIED
Manufacturer : AtlasIED
Manufacturer Part Number : IPS-ZC4
Product Line : IP Hardware/Endpoints
Product Model : IPS-ZC4
Product Name : SIP-to-Analog Controller with 4-Zones
Product Type : VoIP Gateway
Weight (Approximate) (g) : 725.748
Wireless LAN : No
Network & Communication
Ethernet Technology : Fast Ethernet
Network Standard : 10/100Base-T
Depth : 1.2"
Depth (mm) : 30.988
Form Factor : Desktop Mount
Height : 6.2"
Height (mm) : 157.48
Weight (Approximate) : 1.6 lb
Width : 4.5"
Width (mm) : 114.3
PoE (RJ-45) Port : Yes
Limited Warranty : 1 Year
