AtlasIED SHS-6T2CVR Strategically Hidden Speaker with included Clean Room Cover
SHS-6T2CVR
|AT-SHS6T2CVR
Shop All AtlasIED
AtlasIED SHS-6T2CVR Strategically Hidden Speaker with included Clean Room Cover
SHS-6T2CVR | AT-SHS6T2CVR
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
The SHS-6T2CVR is an industry-first strategically hidden ceiling speaker designed specifically for areas where there is high sensitivity to clean air. The included SHS-CVR (cover) easily installs over the SHS opening to create a barrier between the building plenum and clean space. AtlasIED recommends using the SHS-6T2CVR kit when paging notifications are just as important as the air quality in an environment. Easy Installation Visually, only a 3-inch diameter lens and a micro trim ring are visible on the front of the ceiling. The SHS is an installer’s dream with an integrated rail system. All the installation parts are built into the enclosure including the tile rails, which require no rail screws for installation. Simply pull the four rails out from the enclosure and it’s ready for install, drill a three-inch hole in the ceiling tile, set the speaker through the hole and add the clean room cover.
Specifications
ADI Part Number AT-SHS6T2CVR Brand Name AtlasIED Manufacturer AtlasIED Manufacturer Part Number SHS6T2CVR Product Model SHS-6T2CVR Product Name SHS-6T2CVR Speaker Product Type Speaker
Impedance 4 Ohms Sensitivity 86dB
Maximum Frequency Response 15 kHz Minimum Frequency Response 100Hz RMS Output Power 75W
NDAA Compliant Yes TAA Compliant Yes
Depth 3.92" Height 12.7" Width 12.7"
Mount Type Ceiling Mount
Limited Warranty 60-Month
Country of Origin CN Package Contents - SHS-6T2CVR Speaker
- Enclosure
- Tile Bridge
- Durable Rubber Cover
