Camden CM-46/4-WT 4-1/2" Square Push Plate Switch, Exposed Screws, 'WHEELCHAIR' Symbol and 'PUSH to OPEN', Text in Blue
Camden CM-46/4-WT 4-1/2" Square Push Plate Switch, Exposed Screws, 'WHEELCHAIR' Symbol and 'PUSH to OPEN', Text in Blue
- 4 stud switch design and rubber dAers for quieter operation
- Large variety of graphics options
- Available in a range of architectural finishes
- 4 stud switch design and rubber dAers for quieter operation
- Large variety of graphics options
- Available in a range of architectural finishes
- 4 stud switch design and rubber dAers for quieter operation
- Large variety of graphics options
- Available in a range of architectural finishes

Camden CM-46/4-WT 4-1/2" Square Push Plate Switch, Exposed Screws, 'WHEELCHAIR' Symbol and 'PUSH to OPEN', Text in Blue
CM-46/4WT | CM-464WT
Please sign in to view pricing and availability and to add to cart.
Accessories
Product Overview
CM-45 (concealed screws) and CM-46 Series (exposed screws) 4-1/2" square push plate switches mount to standard single/double gang electrical boxes. The SPDT (and optional DPDT) switches are rated 15 amps @ 30 VDC. Push switches are offered with different graphics in various architectural finishes. Weather resistant and water tight configurations also available.
NEW: CAMDEN PUSH PLATE SWITCHES NOW FEATURE STANDARD WATER RESISTANCE - NO NEED TO SELECT 'WR' OPTION!
Note: Optional architectural finishes available for CM-45 Series only by special order. Purchase order cannot be cancelled following issue of order confirmation and product cannot be returned for credit. A min. of 14 business days is required for production.
Main Features
- 4 stud switch design and rubber dAers for quieter operation
- Large variety of graphics options
- Available in a range of architectural finishes
General Information
Specifications
-
ADI Part Number CM-464WT Brand Name Camden Door Controls Manufacturer Camden Door Controls Manufacturer Part Number CM-46/4WT Product Model CM-46/4WT Product Name CM-46/4WT Push Button Product Series CM-46 Product Type Push Button Weight 15.20 oz
-
Gang Type Double Gang, Single Gang
-
Application/Usage Commercial, Door, Hospital, Indoor/Outdoor, Industrial, Residential, Traffic Color Silver Durability Heavy Duty Material Stainless Steel
-
Input Voltage 12V DC, 24V DC, 30V DC
-
Finishing Stainless Steel Print/Message Handicap Logo, Push To Open
-
Limited Warranty 3-Year
-
ADA Compliant Yes Additional Information WEATHERPROOF OPTIONS:
- CM-XXX-WT ADD 'WT' TO PRODUCT # FOR BOOT AND WATER TIGHT COATING
Country of Origin CA Features Flush Mount, Momentary On/Off Mode, Surface Mount, Wall Mountable
