OCC DX024TALT9QPI8 24-Fiber OM3 Ultra-Fox Plenum Interlocked Armor, 50/125um, Aqua Jacket
DX024TALT9QPI8
|JQ-DX024TALM
Shop All OCC
OCC DX024TALT9QPI8 24-Fiber OM3 Ultra-Fox Plenum Interlocked Armor, 50/125um, Aqua Jacket
DX024TALT9QPI8 | JQ-DX024TALM
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
Ideal for industrial and other installations requiring a metallic conduit Interlocking pre-loaded armor may eliminate the need for conduit, reducing installation costs.
Main Features
- Used in trunking, LAN and distribution applications where small size, lightweight, and versatile installation capability are required for ducts, plenums, and air handling spaces
- Ideal configuration for a single termination point requiring multiple fibers
- Aluminum interlocking armor with Low-Smoke PVC overjacket
- Interlocking armor can be easily removed leaving an intact inner cable
- Greater flexibility than corrugated steel armored (CST) cables
- Ideal for locations that require conduit for cable protection
- Indoor/Outdoor plenum cables eliminate the need for costly cable transitions in different installation environments
- UL Listed in accordance with NEC section 770.179(a) for use in ducts, plenums and air-handling spaces
- Low-smoke PVC inner and outer jackets
- 2 to 24 fibers
General Information
Name: OCC DX024TALT9QPI8 24-Fiber OM3 Ultra-Fox Plenum Interlocked Armor, 50/125um, Aqua Jacket
Category: OCC, Wire & Cable, Fiber Optic Cables & Cords, Fiber Optic Cables
UPC Code:
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number JQ-DX024TALM Brand Name OCC Manufacturer Part Number DX024TALT9QPI8
Armored Yes Core/Cladding Diameter 900 µm Fiber Category OM3 Fiber Count 24 Fiber Optic Mode Multimode Jacket Material PVC Jacket Type Plenum
Color Blue
Environmental Certification ANSI/NFPA 262, ICEA-S-83-596, UL 1651 Features 2 to 24 fibers, 900 µm buffer eliminates the need for costly and time-consuming installation of fanout kits or pigtail splices because connectors terminate directly to the fiber, Cable materials are Indoor/Outdoor UL-Listed OFCP and also UV, water and fungus resistant, Can be installed outside and in plenum or riser pathways inside, eliminating the need to transition cable types between environments, Helically stranded core for flexibility, survival in difficult installations and mechanical protection for the fibers, High performance tight-buffered coating on each fiber for environmental and mechanical protection, Low-smoke PVC inner and outer jackets, UL Listed in accordance with NEC section 770.179(a) for use in ducts, plenums and air-handling spaces
