Product Overview
OCC's Category 5e Bezel jacks utilize our patented PC Board technology to exceed the TIA 568-C.2 Cat 5e requirements with headroom to spare. For a more cost effective solution, OCC also offers a Leadframe Bezel jack that utilizes our patented Leadframe technology. 110-style punch downs accommodate 22 AWG sold through 26 AWG solid and 24 AWG stranded conductors and each OCC jack offers universal T568A/B wiring and performance enhancements to exceed industry standards.
Main Features
- Meets IEC 60603-7 requirements
- 110-style IDC contacts meet TIA 568-C.2 requirements
- ETL Verified to TIA 568-C.2 Cat 6
- Backward compatible, Cat 3, 5, and 5e compliant
- Full 6-position, modular plug compatible with bezel
- Universal T568A/B wiring for easy installation
- Available with 20 labeling and color options
- Secure mounting locks jack into faceplate
- Fits all OCC UMJ faceplates and surface mount boxes
- Dielectric withstand-1000 VAC RMS, AC 60Hz or 1414 VDC
General Information
Name: OCC KMJL06U04 6-Position CAT3 Modular USOC Jack Connector, Green
Category: OCC, Data Comm & Networking, Cable Connectors, Keystone Jacks
UPC Code:
Country of Origin: . Country of origin is subject to change.
Specifications
-
ADI Part Number JQ-KMJL06U04 Brand Name OCC Manufacturer OCC Manufacturer Part Number KMJL06U04
-
Contact Plating Gold
-
Color Green
-
Environmental Certification UL Features 110 style IDC contacts, Available in 12 color options, Compliant with Power over Ethernet (PoE+) requirements, DC current rating- 1.5 A per conductor at 20 deg C ambient de-rated to 0.5 A at 60 deg C ambient, Dielectric withstand- 1000VAC RMS, AC 60Hz or 1414 VDC P-P, Fits all OCC Keystone faceplates and surface mount boxes, Insulation 500MOhm Minimum, Meets IEC 60603-7 requirements, One-piece stuffer cap included
