Product Overview
Category 6 Ethernet cable for high-speed, indoor deployments
The U-Cable-C6-CMR is a Category 6 UTP cable that supports speeds up to 1Gbps with its 23 AWG solid copper, twisted pair conductor. The conductor's small diameter, combined with the cable's anti-crosstalk divider, isolates and protects signals from interference. The U-Cable-C6 is also a CMR cable with a fire-resistant jacket that ensures safe operation across multiple floors and vertical shafts. Category 6 Ethernet connectors are recommended to accommodate the conductor's size and optimize its performance.
Features:
- Category 6 Unshielded Twisted Pair (UTP) cable
- Communications Multipurpose Cable, Riser (CMR)-rated, fire-resistant jacket
- 1,000 ft (305 m)
- 23 AWG solid copper, twisted pair conductor
- Anti-crosstalk divider
- For 1000BASE-T Ethernet applications
General Information
Name : Ubiquiti U-CABLE-C6-CMR UniFi CAT6 Indoor Ethernet Cable, CMR , Ubiquiti
Category : Category 6 Network Cables
UPC Code : 810354026249
Country of Origin : +1. Country of origin is subject to change.
Specifications
General Information
ADI Part Number : KX-UCABLEC6C
Brand Name : Ubiquiti
Manufacturer : Ubiquiti Inc.
Manufacturer Part Number : U-CABLE-C6-CMR
Product Line : UniFi
Product Model : U-CABLE-C6-CMR
Product Name : UniFi Indoor Cable CMP
Product Series : UniFi
Product Type : Indoor Cable
Technical Information
American Wire Gauge : 23AWG
Cable Characteristic : Ethernet cable
Cable Rating : Riser
Cable Type : Category 6
Device Supported : Network Device
Frequency / Bandwidth Rating : 600 MHz
Jacket Material : PVC
Shielding : Yes
Solid or Stranded : Solid
Audio
Shipping Weight (Approximate) (g) : 14741.75
Media & Performance
Data Transfer Rate : 10/100/1000 Base-T
Data Transfer Rate (Bps) : 134217728
Physical Characteristics
Cable Length : 305 m
Cable Length (mm) : 305000
Color : White
Miscellaneous
Environmental Certification : ANSI/TIA-568-C.2, CSA 22.2 NO.214, IEC 61156-5, ISO/IEC 11801, LVD, NFPA 262, RoHS2, UL 444
Environmentally Friendly : Yes
Features : Anti-crosstalk divider, Category 6 UTP communications multipurpose cable, Riser (CMR)-rated, fire-resistant jacket
