Ubiquiti USW-INDUSTRIAL 8-Port Industrial Layer 2 PoE Switch, Black
USW-INDUSTRIAL|KX-USWINDUS
Ubiquiti USW-INDUSTRIAL 8-Port Industrial Layer 2 PoE Switch, Black
USW-INDUSTRIAL|KX-USWINDUS
Key Features
- Auto-Sensing IEEE 802.3af/at/bt PoE
- Fanless Industrial-Grade Design
- Plenum-Rated Form Factor
Key Features
- Auto-Sensing IEEE 802.3af/at/bt PoE
- Fanless Industrial-Grade Design
- Plenum-Rated Form Factor
Sign In for Dealer Pricing
Become an ADI CustomerKey Features
- Auto-Sensing IEEE 802.3af/at/bt PoE
- Fanless Industrial-Grade Design
- Plenum-Rated Form Factor
Ubiquiti
Ubiquiti USW-INDUSTRIAL 8-Port Industrial Layer 2 PoE Switch, Black
USW-INDUSTRIAL | KX-USWINDUS
Please sign in to view pricing and availability and to add to cart.
Accessories
Battery Packs
ADI # WT-OVRC1500U
MODEL # WT-OVRC1500U
WT-OVRC1500U|WT-OVRC1500U
Sign In for Dealer Pricing
Overview
Specifications
Documents
Product Overview
Expand your industrial network capacity to support IP cameras, VoIP phones, access points, network-connected LED panels, and more with the rugged UniFi Switch Industrial 10-Port Gigabit PoE++ Compliant Managed Switch from Ubiquiti Networks. Featuring a durable industrial design, this fully managed network switch is equipped with ten Gigabit Ethernet ports, eight of which are IEEE 802.3bt PoE++ complaint — delivering up to 60W per port with a total power budget of 430W. The switch also has a 20 Gb/s (10 Gb/s non-blocking) switching capacity with a 14.88 Mpps forwarding rate for fast and reliable data transfers. Its die-cast aluminum enclosure has a black powder coat finish that's made to resist corrosion and withstand extreme temperature variations. Additionally, the UniFi Switch Industrial is rated for use in plenum spaces and can be mounted on a desk or a wall using the included kit, where its fanless design allows it to operate silently in the background. Use the UniFi Network Controller to configure, manage, and monitor the UniFi Switch Industrial alongside its connected devices.
Main Features
- Auto-Sensing IEEE 802.3af/at/bt PoE
- Fanless Industrial-Grade Design
- Plenum-Rated Form Factor
- 10 x Gigabit Ethernet Ports
- 8 x PoE++ Compliant 60W Ports
General Information
Name: Ubiquiti USW-INDUSTRIAL 8-Port Industrial Layer 2 PoE Switch, Black
Category: Ubiquiti, Video Surveillance, Data Comm & Networking, Networking Devices, Hubs, Routers & Switches, Network Switches, Network Switches
UPC Code: 817882028974
Country of Origin: +1. Country of origin is subject to change.
Specifications
-
ADI Part Number KX-USWINDUS Brand Name Ubiquiti Manufacturer Ubiquiti Inc. Manufacturer Part Number USW-INDUSTRIAL Product Line UniFi Product Model USW-INDUSTRIAL Product Name Ubiquiti Networks UniFi Switch Industrial 10-Port Gigabit PoE++ Compliant Managed Switch Product Series USW Product Type Network Switch Weight 8.5 lb
-
Media Type Supported Twisted Pair Network Switch Type Industrial, L2, PoE Power Consumption 20W
-
Network (RJ-45) Yes Total Number of Network Ports 8
-
Manageable Yes
-
Network Technology 10/100/1000Base-T
-
Ethernet Technology 10 Gigabit Ethernet Layer Supported 2
-
Color Black Depth 9.3" Height 2.4" Material Die-cast Aluminum Width 10"
-
Frequency 50 Hz|60 Hz Input Voltage 100-240V AC PoE (RJ-45) Port Yes PoE Budget 430W Power Source AC, DC
-
Limited Warranty 1-Year
-
Environmentally Friendly Yes Features 10 x Gigabit Ethernet Ports, 14.88 Mpps Forwarding Rate, 20 Gb/s Switching Capacity, 8 x PoE++ Compliant 60W Ports, Fanless, silent cooling
