LEA Professional CONNECT 34D 4-Channel x 30W 4U 8U 70V
CONNECT 34D|LD-CONNCT34D
LEA Professional CONNECT 34D 4-Channel x 30W 4U 8U 70V
CONNECT 34D|LD-CONNCT34D
Key Features
- 3 Ways To Connect
- Web Browser-Based Ui
- Cloud Control
Key Features
- 3 Ways To Connect
- Web Browser-Based Ui
- Cloud Control
Sign In for Dealer Pricing
Become an ADI CustomerKey Features
- 3 Ways To Connect
- Web Browser-Based Ui
- Cloud Control
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
The CONNECTSERIES 34D is a 4-channel amplifier with 30W per channel in a ½ rack space form factor. As part of the Dante CONNECTSERIES, the world’s first Internet of Things- (IoT) enabled professional-grade amplifiers, it is perfectly suited for small to medium-scale installations. The 34D features direct HiZ (70V or 100V) or LoZ selectable by channel. With three ways to connect, you can engage the built-in Wi-Fi access point, connect to the venue’s Wi-Fi, or use the FAST Ethernet to connect to any local area network via Cat5 or Cat6 cable.
Main Features
- 3 Ways To Connect
- Web Browser-Based Ui
- Cloud Control
- Direct Low-Z and Hi-Z
- Smart Power Bridge
- Universal Switch-Mode Power Supply
- Analog Balanced Or Unbalanced Inputs
- 96KHz Analog Devices Dsp
- External I/O Port
- Highly Efficient Class-D Output Stage
General Information
Name: LEA Professional CONNECT 34D 4-Channel x 30W 4U 8U 70V
Category: LEA Professional, Pro AV, Commercial Audio, Pro Amplifiers
UPC Code: 850011348307
Country of Origin: . Country of origin is subject to change.
Specifications
-
ADI Part Number LD-CONNCT34D Brand Name LEA Professional Manufacturer Part Number CONNECT 34D Product Name Connect 34D A/V Receivers and Amplifiers Product Type A/V Receiver and Amplifier Weight 7 lb
-
Maximum Frequency Response 20 kHz Minimum Frequency Response 20 Hz
-
Height 1.71" Width 8.58"
-
Input Voltage 100-240V AC
-
Length 11.82"
-
Frequency Band 20-20000 Hz
-
Limited Warranty 5-Year
