Image of LV-SPSCS12V
Shop All Leviton

Leviton SPSCS-12V SDX Splice Module with 12-Fiber OS2 SC/APC Pigtails, Green

SPSCS-12V | LV-SPSCS12V

Please sign in to view pricing, availability, and to add to cart.

Overview
Specifications
Documents

Product Overview

SDX 12- and 24-Fiber Metal Modules protect and organize heat-shrink fusion spliced fibers (up to 12 or 24 fibers) inside a fiber enclosure. The modular design enables faster field splicing and simple management of pigtails within the housing. Splice modules eliminate the need for individual splice trays within a fiber enclosure and provide optimal organization and slack management of fibers. Typical applications include Wide Area Networks (WAN), campus environments, high-count riser buildings, government installations, data centers, and central offices. Fiber pigtail fusion splice modules shall be offered in 12- or 24-fiber LC and 12-fiber SC configurations in OS2 (UPC and APC) OM3 and OM4 fiber types. Construction of module shall be of 14-gauge aluminum for robustness and light weight. Splice Modules shall be pre-loaded and routed with respective one-meter, color-coded pigtail assembly. Individual pigtails shall have maximum insertion loss of 0.4 dB for OM3/ OM4 and 0.35 dB for OS2 fiber types. Return Loss shall be greater than 25 dB (for OM3 and OM4), 55 dB (for OS2/ UPC), and 60 dB (for OS2/APC). Individual compartments shall provide slack storage and bend radius protection for incoming backbone fibers, 900 µm tight-buffer fibers, and fusion-spliced fibers. Incoming 250 µm backbone fibers shall be protected by a braided mesh sleeve. Heat-shrink style splice sleeves, braided mesh sleeve, and tie wraps shall be included with module.

Main Features

  • Module integrates fiber adapter bulkhead (12 or 24 fibers) and splice holders, eliminating the need of splice trays
  • Offered in single-mode (OS2) UPC and APC and laser optimized multimode (OM3) fiber types
  • Other fiber types available as special orders
  • Individual compartments provide slack storage and bend radius guides for respective backbone cable, 900 μm tight buffer pigtails, and fusion-spliced fibers
  • 12-fiber, color-coded 900 μm tight buffer pigtails are 1 meter and pre-loaded in module per specific configuration
  • Modular design allows for ease of maintenance of individual spliced fiber and allows for scaling up without impacting existing fibers
  • Accessory kit consists of 40 mm heat shrink style splice sleeves, tie wraps, and braided mesh sleeve

General Information

Name: Leviton SPSCS-12V SDX Splice Module with 12-Fiber OS2 SC/APC Pigtails, Green
Category: Leviton, Data Comm & Networking, Patch Panels, Fiber Optic Patch Panels
UPC Code: 078477655931
Country of Origin: United States.Country of origin is subject to change.
