Ortronics LM2-LC24J M2 Cassette, 24-Fiber, LC Quad to MPOM, OS2, Universal Polarity
LM2-LC24J|OR-LM2LC24J
Ortronics LM2-LC24J M2 Cassette, 24-Fiber, LC Quad to MPOM, OS2, Universal Polarity
LM2-LC24J|OR-LM2LC24J
Key Features
- When combined with Infinium Core Trunks and Infinium Core Patch Cords Total System Loss 2.5 dB Total Return Loss 19 dB
- Single-mode total channel connection loss 2.1 dB - Single-mode total channel connection return loss 49 dB - Multimode total channel connection loss 2.5 dB - Multimode total channel connection return loss 19 dB
- 12 or 24-fiber cassette compatible with Q-Series Enclosures
Key Features
- When combined with Infinium Core Trunks and Infinium Core Patch Cords Total System Loss 2.5 dB Total Return Loss 19 dB
- Single-mode total channel connection loss 2.1 dB - Single-mode total channel connection return loss 49 dB - Multimode total channel connection loss 2.5 dB - Multimode total channel connection return loss 19 dB
- 12 or 24-fiber cassette compatible with Q-Series Enclosures
Key Features
- When combined with Infinium Core Trunks and Infinium Core Patch Cords Total System Loss 2.5 dB Total Return Loss 19 dB
- Single-mode total channel connection loss 2.1 dB - Single-mode total channel connection return loss 49 dB - Multimode total channel connection loss 2.5 dB - Multimode total channel connection return loss 19 dB
- 12 or 24-fiber cassette compatible with Q-Series Enclosures

Ortronics by Legrand
Ortronics LM2-LC24J M2 Cassette, 24-Fiber, LC Quad to MPOM, OS2, Universal Polarity
LM2-LC24J | OR-LM2LC24J
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
Q-Series M2 Standard Density Cassettes are part of a complete fiber solution. When combined with matched Infinium Trunks and Infinium Patch Cable Assemblies the solution enables industry leading pre- terminated performance and universal polarity for simple, fast and consistent and simplified installation. Compatible with Q-Series Rack Mount or Wall Mount Fiber Enclosures.
Main Features
- When combined with Infinium Core Trunks and Infinium Core Patch Cords Total System Loss 2.5 dB Total Return Loss 19 dB
- Single-mode total channel connection loss 2.1 dB - Single-mode total channel connection return loss 49 dB - Multimode total channel connection loss 2.5 dB - Multimode total channel connection return loss 19 dB
- 12 or 24-fiber cassette compatible with Q-Series Enclosures
- Supports either Single-mode OS2 or Multimode Infinium Core fiber
- Polarization-Universal
- LC adapter with Internal shutter Provides eye safety by attenuating laser light when the mated connector is removed
- 100%automatic shutter mechanism requiring no operator handling of the shutter door
- Compatible with standard LC connectors
- It keeps adapters interior clean from dust
- You can see the visible light through the adapter
General Information
Name: Ortronics LM2-LC24J M2 Cassette, 24-Fiber, LC Quad to MPOM, OS2, Universal Polarity
Category: Ortronics by Legrand, Data Comm & Networking, Patch Panels, Fiber Optic Cassettes
UPC Code:
Country of Origin: United States. Country of origin is subject to change.
Specifications
-
ADI Part Number OR-LM2LC24J Brand Name Ortronics by Legrand Manufacturer Part Number LM2-LC24J Product Line Ortronics Product Name Infinium Core M2 Cassette - 24 Fiber - LC Quad to MPOM - OS2 - Universal Polarity Product Type Cassette
-
Connector on First End LC
-
Depth 4.87" Height 1.19" Width 5.13"
-
Country of Origin US
