Product Overview
8-position, industrial connector shall be applicable for use in manufacturing environments and shall meet/exceed the ANSI/TIA-568-C.2 standard for Category 6 performance requirements. Bulkhead RJ45 jack and plug shall incorporate an IP67 rated seal and shall be designed to provide protection from dust and temporary immersion in water typically found in harsh industrial environments. Tethered protective cap shall ensure IP67 rotection of the connector and plug in the unmated condition. Secondary seals on both the connector and plug shall provide an additional environmental barrier. Termination to a 4-pair 24 AWG 100 ohm twisted pair cable shall not require the use of a punchdown tool. An IP67 rating shall be achieved when mated with an IP67 and NEMA UL Type 12 industrial grade, bayonet style patch cord.
Main Features
- Industrial CAT6 RJ45 UTP Bulkhead Connector
- Meets/exceeds ANSI/TIA-568-C.2 standards
- IP67 rated for dust and water protection
- Tethered cap ensures IP67 protection when unmated
- Secondary seals for additional environmental barrier
- Tool-less termination for 4-pair 24 AWG cable
- Compatible with IP67 and NEMA UL Type 12 patch cords
General Information
Specifications
ADI Part Number P9-IAEBH6 Brand Name Panduit Manufacturer PANDUIT CORP Manufacturer Part Number IAEBH6 Packaged Quantity 1 Product Line IndustrialNet Product Name IndustrialNet UTP Network Connector Product Type Network Connector
Cable Type Category 6 Contact Plating Gold Impedance 100 ohms
Connector Type RJ45
Color Black
Country of Origin US Environmentally Friendly Yes Features Bulkhead anti-rotation washer, Forward motion termination, PoE, Protective Cap, Robust construction
