Hanwha PNO-A9081R/KAP Series 8MP AI IR Bullet Camera, 4.5-10mm Varifocal Lens, Dark Gray, TAA Compliant
PNO-A9081R/KAP
|SQ-OA981RKAP
Shop All Hanwha Vision
Hanwha PNO-A9081R/KAP Series 8MP AI IR Bullet Camera, 4.5-10mm Varifocal Lens, Dark Gray, TAA Compliant
PNO-A9081R/KAP | SQ-OA981RKAP
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
Wisenet AI cameras using AI algorithms filter out irrelevant movements caused by environmental changes such as waving trees, shadows, or animals. While conventional cameras detect motion based on its pixels and generate events even if users want to ignore, Deep Learning-based Wisenet AI cameras generate event alarm only for people and vehicles, reducing false alarms for more efficient operation.
Main Features
- Maximum 4K resolution
- 0.05Lux at F1.6 (Color), 0Lux (B/W, IR LED on)
- Day and night(ICR), WDR(120 dB), WiseNRⅡ (Using AI engine), prefer shutter
- H.265, H.264, MJPEG codec, WiseStreamⅡ, WiseStreamⅢ (Using AI engine)
- Video Analytics based on AI
- Requires camera firmware v1.41.03 or later to use Face Mask Detection
- System requirements
General Information
Name: Hanwha PNO-A9081R/KAP Series 8MP AI IR Bullet Camera, 4.5-10mm Varifocal Lens, Dark Gray, TAA Compliant
Category: Hanwha Vision, Video Surveillance, IP Cameras, Bullet Cameras
UPC Code: 8801089171948
Country of Origin: Korea. Country of origin is subject to change.
Specifications
ADI Part Number SQ-OA981RKAP Brand Name Hanwha Vision Country of Origin KR Manufacturer Hanwha Vision Manufacturer Part Number PNO-A9081R/KAP Product Model PNO-A9081R/KAP Product Name 4K AI IR Bullet Camera Product Series P Product Type Bullet Camera
Aspect Ratio 16:9 Connectivity Technology Wired Field of View Diagonal, Horizontal, Vertical Field of View (Horizontal) 101.4° Field of View (Vertical) 53.60° Lens Type Varifocal Maximum Aperture f/1.6 Maximum Frame Rate 30fps Minimum Focal Length 4.50mm Night Vision Yes Night Vision Type Infrared (IR) Optical Zoom 2.2x Video Formats H.264, H.265, MJPEG Wide Dynamic Range Yes
Image Sensor Type CMOS Night Vision Distance 98.43'
Ingress Protection Rating IP66, IP67 TAA Compliant Yes
Maximum Video Resolution 3840 x 2160
Maximum Operating Temperature 131°F Minimum Operating Temperature -40°F Operating Humidity 90% RH
Longest Shutter Speed 1/5 Second Minimum Illumination 0.0050lux Shortest Shutter Speed 1/12,000 Second
Network (RJ-45) Yes
Lens Included Yes Maximum Focal Length 10.00mm Minimum Aperture f/2.65
Remote Management Yes
Color Gray Durability Dustproof, Impact Resistant, Waterproof Weight 5.47lb
Input Voltage 12V DC
Diameter 3.58" Mount Type Backbox Mount, Corner Mount
Recording Formats 4K Storage Type Memory Card
Analog Video Signal Format CVBS Maximum Resolution 1280 x 720
Features 0.05Lux at F1.6 (Color), 0 Lux (B/W IR LED On), 30fps at all resolutions (H.265/H.264), 30m (98ft) IR illumination, 4.5-10mm (2.2x) motorized varifocal lens, 4K/8 MP (3840 x 2160) resolution, Day and Night (ICR), WDR (120dB), P-Iris, Digital image stabilization with built-in Gyro sensor, H.265, H.264, MJPEG codec supported, Multiple streaming, Object detection and classification (Person, Face, Vehicle, License Plate), Attribute, BestShot, Video Analytics based on AI Impact Protection Rating IK10
