Hanwha XRN-1620B2-36TB NVR, 16-Channel 8K NVR, 36TB Raw, H265, H264, MJPEG
XRN-1620B2
|SQ-X1620B236
Shop all Hanwha Vision
Hanwha XRN-1620B2-36TB NVR, 16-Channel 8K NVR, 36TB Raw, H265, H264, MJPEG
XRN-1620B2 | SQ-X1620B236
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
Hanwha's XRN-1620B2 is an 8K NVR (Intel-based), 16 channels, H265,H264, MJPEG compression support. Supports up to 8 fixed internal SATA HDDs (10TB max per HDD), ARB (Automatic Recovery Backup), 140 Mbps recording / up to 32 Mbps playback, Dual stream recording, WiseStream technology, HDMI/VGA dual display, maximum resolution of 32MP recording/display and fisheye dewarping on web and CMS, web UI 2.0 (plugin-free), AI search (Wisenet AI cameras only), QR Code for mobile app.
Main Features
- Up to 16 channels, Supports up to 32MP camera resolution
- 140 Mbps network camera recording
- Support 4K video out on HDMI monitor
- Support dual monitor HDMI/VGA video out
- H.265, H.264, MJPEG compression
General Information
Name: Hanwha XRN-1620B2-36TB NVR, 16-Channel 8K NVR, 36TB Raw, H265, H264, MJPEG
Category: Hanwha Vision, Video Surveillance, Recording Devices & Servers, Network Video Recorders (NVRs), ADI Pro Rewards
UPC Code: 849688017630
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number SQ-X1620B236 Bandwidth 140 Mbps Brand Name Hanwha Vision Manufacturer Hanwha Group Manufacturer Part Number XRN-1620B2-36TB Product Model XRN-1620B2 Product Name XRN-1620B2 16CH 4K 140Mbps H.265 NVR Product Type Video Surveillance Station
Connectivity Technology Wired Effective Camera Resolution 32MP Maximum Frame Rate 480fps Number of Channels 16 Storage Capacity 36TB Video Formats H.264, H.265, MJPEG
HDMI Yes
Ethernet Yes Remote Management Yes
Depth 17" Width 17"
Recording Formats 8K
Maximum Resolution 8160 x 6120
