Hanwha XRN-3220B4-40TB 8K NVR, 32-Channel, 40TB, 16 SATA HDD, Video Surveillance Systems
XRN-3220B4-40TB
|SQ-X3220B440
Shop all Hanwha Vision
Hanwha XRN-3220B4-40TB 8K NVR, 32-Channel, 40TB, 16 SATA HDD, Video Surveillance Systems
XRN-3220B4-40TB | SQ-X3220B440
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
Hanwha Vision, a global vision solution provider, launched X series NVR lineup is equipped with Intel 12th generation processor, making it compliant with NDAA. It also has built-in TPM which provides robust cybersecurity.
Main Features
- 32-Channel, 32MP resolution
- SATA 16ea (up to 160TB)
- Up to 520Mbps recording / transmission bandwidth
- Easy Channel/Event/Alarm configuration
- Virtual channal view
- Dynamic layout
- Built-in browser supportmanagement (up to 100 set)
- Compatible with Wisenet Viewer, Wisenet mobile
- Manual event support
General Information
Name: Hanwha XRN-3220B4-40TB 8K NVR, 32-Channel, 40TB, 16 SATA HDD, Video Surveillance Systems
Category: Hanwha Vision, Video Surveillance, Recording Devices & Servers, Network Video Recorders (NVRs), ADI Pro Rewards
UPC Code: 849688021316
Country of Origin: Vietnam. Country of origin is subject to change.
Specifications
ADI Part Number SQ-X3220B440 Brand Name Hanwha Vision Manufacturer Part Number XRN-3220B4-40TB
Maximum Frame Rate 30 fps Number of Channels 32 Video Formats H.264, H.265, MJPEG
Recording Modes Continuous, Event, Post-event, Pre-event, Schedule
Maximum Video Resolution 3840 x 2160
HDMI Yes USB Standard USB 2.0, USB 3.0
Ethernet Yes
ADI Part Number Replaces SQ-X3210B440 Model Number Replaces XRN-3210B4-40TB
Color Black Depth 22.4" Height 5.19" Weight 30.9lb Width 17.32"
Input Voltage 100-240V AC
Hard Drive Capacity 40TB
Environmental Certification CE, FCC, UL Environmentally Friendly Yes Operating System Compatibility Android, Apple iOS
