Hanwha XNV-C7083R/KEX Series 4MP Outdoor IR Vandal Dome IP Camera, 2.8-12mm Motorized Varifocal Lens, White, TAA Compliant
XNV-C7083R/KEX
|SQ-XV783RKEX

Hanwha XNV-C7083R/KEX Series 4MP Outdoor IR Vandal Dome IP Camera, 2.8-12mm Motorized Varifocal Lens, White, TAA Compliant
XNV-C7083R/KEX | SQ-XV783RKEX
Please sign in to view pricing, availability, and to add to cart.
Product Overview
The new X series cameras utilize AI to detect and classify people, vehicles, faces, license plates and more in real-time. With a range of available resolutions from 2MP to 4K, the cameras’ deep-learning algorithms can reliably identify multiple distinct objects. Reduce false alarms due to none interesting motion, like wind-blown trees, shadows, or animals. Analytics become a reliable second pair of eyes to operators helping them know where to look for important real-time events, while making post-event forensic searches highly efficient.
Main Features
- 4MP resolution
- 2.8~10 mm (3.6x) motorized varifocal
- Color: 0.038 Lux (F1.4, 1/30sec, 30IRE), 0 Lux (IR LED on)
- Maximum 60 fps (H.265/H.264)
- WiseIR: IR viewable length 40 m (131.23 ft)
- Day & Night (ICR), extremeWDR (120 dB)
- Hard-coated dome bubble
- WiseNR(Based on AI engine), WiseStream III(Based on AI engine)
- Analytics events based on AI engine (NPU) : Object detection (Person/Face/Vehicle - car, truck, bus, bicycle, motorcycle/License plate)
- IVA (Virtual line/Area, Enter/Exit, Loitering, Direction, Intrusion)
General Information
Specifications
ADI Part Number SQ-XV783RKEX Brand Name Hanwha Vision Manufacturer Hanwha Vision Manufacturer Part Number XNV-C7083R/KEX Product Model XNV-C7083R/KEX Product Name 4MP AI IR Vandal Dome Product Series X Product Type Dome Camera
Connectivity Technology Wired Effective Camera Resolution 4MP Field of View Diagonal, Horizontal, Vertical Field of View (Horizontal) 110° Field of View (Vertical) 61° Maximum Aperture f/1.4 Maximum Frame Rate 60fps Minimum Focal Length 2.8mm Night Vision Yes Night Vision Type Infrared Optical Zoom 3.6x Video Formats H.264, H.265, MJPEG
Image Sensor Type CMOS Night Vision Distance 131.23 ft Wide Dynamic Range Yes
Ingress Protection Rating IP66, IP67 TAA Compliant Yes
Maximum Video Resolution 2592 x 1520
Maximum Operating Temperature 131°F Minimum Operating Temperature -40°F Operating Humidity 100% RH (Condensing)
Longest Shutter Speed 1/12000 Second Minimum Illumination 0.0076 lux Shortest Shutter Speed 2 Second
Network (RJ-45) Yes
Focal Length 2.8-10mm Lens Included Yes Maximum Focal Length 10mm Minimum Aperture f/3
Remote Management Yes
Color White Durability Dustproof, Impact Resistant, Vandal Resistant, Waterproof Form Factor Dome Weight 3.20lb
Input Voltage 12V DC
Diameter 6.3" Mount Type Desktop Mount, Rack Mount, Wall Mount
Storage Type Memory Card
Maximum Resolution 1280 x 720
Limited Warranty 3-Year
Country of Origin KR Features Audio Detection, Back Light Compensation (BLC), Day/Night, Defog, Digital Noise Reduction, Gain Control, Highlight Compensation (HLC), Motion Detection, Privacy Masking, White Balance, Wide Dynamic Range Impact Protection Rating IK10 Indoor/Outdoor Outdoor
