Eaton Tripp Lite B126-1A1-IR HDMI Over CAT5/6 Active Extender Kit with IR Control, Box-Style Transmitter and Receiver, Video/Audio, 1080P, up to 125', TAA
B126-1A1-IR
|TC-B1261A1IR
Shop All Eaton Tripp Lite
Eaton Tripp Lite B126-1A1-IR HDMI Over CAT5/6 Active Extender Kit with IR Control, Box-Style Transmitter and Receiver, Video/Audio, 1080P, up to 125', TAA
B126-1A1-IR | TC-B1261A1IR
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
The B126-1A1-IR HDMI over CAT5/6 Active Extender Kit includes a transmitter unit and a receiver unit that work in tandem to extend HDMI audio/video and IR remote control signals to a projector, monitor or television. The kit is ideal for digital signs, trade shows, classrooms, churches, offices, retail settings and other applications where the source is located farther than conventional cables allow. HDMI cable connects a local display and the audio/video source to the transmitter unit and a remote display to the receiver unit. CAT5e/6 cable connects the two units (for best results, use 24AWG solid-wire CAT5e/6 cable, such as N202-Series). Included IR-IN and IR-OUT cables allow you to control the video source, such as a media server, while standing at the remote display. The B126-1A1-IR can extend a 1080p (60 Hz) signal up to 125' (38.1m). In addition to crystal-clear video, the B126-1A1-IR delivers full, rich stereo and 7.1-Channel surround sound (multi-channel or PCM) audio. Built-in equalization control lets you fine-tune the image quality at each remote display. Supports 24-Bit True Color (8-Bit per channel) and HDCP. Easy to set up with no software or drivers to install. Mounts to a wall, rack or pole using the included hardware.
Specifications
ADI Part Number TC-B1261A1IR Brand Name Eaton Tripp Lite Manufacturer Eaton Manufacturer Part Number B126-1A1-IR Product Model B126-1A1-IR Product Name B126-1A1-IR Video Extender Transmitter/Receiver Product Type Video Extender Transmitter/Receiver
Cable Type Category 6 Connectivity Technology Wired Maximum Operating Distance 200' Media Type Supported Twisted Pair Number of Input Devices Supported 1 Number of Output Devices Supported 1
TAA Compliant Yes
Maximum Video Resolution 1920 x 1080
Network (RJ-45) Yes Number of HDMI Inputs 1 Number of HDMI Outputs 2 Number of Network (RJ-45) Ports 2
Color Black
Mount Type Pole Mount, Rack Mount, Wall Mount
Graphics Modes Full HD
Limited Warranty 1-Year
Country of Origin TW Environmentally Friendly Yes
