Eaton Tripp Lite B126-1P0 HDMI over CAT5, CAT6 Passive Extender, Box-Style Remote Receiver for Video/Audio, up to 100 (30 m), TAA
B126-1P0
|TC-B1261P0
Shop All Eaton Tripp Lite
Eaton Tripp Lite B126-1P0 HDMI over CAT5, CAT6 Passive Extender, Box-Style Remote Receiver for Video/Audio, up to 100 (30 m), TAA
B126-1P0 | TC-B1261P0
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
The B126-1P0 HDMI over CAT5/CAT6 Passive Remote Receiver works with a B126-002 or B126-004 transmitter (sold separately) to extend an HDMI signal to multiple projectors, monitors or televisions in a chain. It's ideal for digital signs, trade shows, presentations, classrooms, churches, retail settings and other applications where the video source is located farther than conventional cables allow. The B126-1P0 can extend a 1080i (60 Hz) signal up to 100' (30.5m) or a 1080p (60 Hz) signal up to 50' (15.2m) with a single CAT5e/6 cable (for best results, use 24AWG solid-wire CAT5e/6 cable, such as N202-Series) between it and the transmitter. The built-in HDMI cable features a latching connector that helps prevent accidental disconnection. No external power is required. In addition to crystal-clear video, the B126-1P0 delivers full, rich stereo and 7.1-Channel surround sound (multi-channel or PCM) audio when paired with a B126-002 or B126-004 transmitter. Supports 24-Bit True Color (8-Bit per channel) and HDCP compatibility. Easy to set up with no software or drivers to install.
Specifications
ADI Part Number TC-B1261P0 Brand Name Eaton Tripp Lite Manufacturer Eaton Manufacturer Part Number B126-1P0 Product Model B126-1P0 Product Name B126-1P0 Video Console Product Type Video Extender Receiver
Cable Type Category 6 Connectivity Technology Wired Maximum Operating Distance 100' Media Type Supported Twisted Pair Number of Input Devices Supported 1 Number of Output Devices Supported 1
TAA Compliant Yes
Maximum Video Resolution 1920 x 1080
Network (RJ-45) Yes Number of HDMI Outputs 1 Number of Network (RJ-45) Ports 1
Color Black Form Factor Desktop Mount
Mount Type Desktop Mount
Limited Warranty 1-Year
Country of Origin TW Environmentally Friendly Yes Package Contents - B126-1P0 HDMI over Cat5/Cat6 Passive Remote Receiver
- Owner’s Manual
