Tripp Lite N784-001-SC-15 10/100 SC Singlemode Fiber to Ethernet Media Converter, 15km
N784-001-SC-15|TC-N7841SC15
Tripp Lite N784-001-SC-15 10/100 SC Singlemode Fiber to Ethernet Media Converter, 15km
N784-001-SC-15|TC-N7841SC15
Tripp Lite by Eaton
Tripp Lite N784-001-SC-15 10/100 SC Singlemode Fiber to Ethernet Media Converter, 15km
N784-001-SC-15Â |Â TC-N7841SC15
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
Tripp Lite's N784-001-SC-15, 10/100 to Singlemode Media Converter ( RJ45 to SC ), is an economical way to extend the distance ( up to 15kM ) of network nodes by converting Cat5e UTP cables to Singlemode Fiber Optic. The Media Converter features automatic MDI/MDI-X configuration, and the UTP port senses the network speed automatically as well. Auto-detects half or full duplex operation on the fiber port. Power supplied by small form factor AC adapter.
Main Features
- 10/100 SC Singlemode Fiber to Ethernet conversion
- Extends network distance up to 15km
- Automatic MDI/MDI-X configuration
- UTP port auto-senses network speed
- Auto-detects half or full duplex operation
- Powered by small form factor AC adapter
General Information
Name: Tripp Lite N784-001-SC-15 10/100 SC Singlemode Fiber to Ethernet Media Converter, 15km
Category: Tripp Lite by Eaton, Video Surveillance, Data Comm & Networking, Networking Devices, Media Converters & Transceivers, Media Converters, Media Converters
UPC Code: 037332184139
Country of Origin: China. Country of origin is subject to change.
Specifications
-
ADI Part Number TC-N7841SC15 Brand Name Tripp Lite by Eaton Manufacturer Tripp Lite Manufacturer Part Number N784-001-SC-15 Product Model N784-001-SC-15 Product Name 10/100 SC Singlemode Media Converter, 15km, 1310nm Product Type Transceiver/Media Converter Â
-
Media Type Supported Optical Fiber, Twisted Pair Â
-
DVI No Management Port No Network (RJ-45) Yes Number of Network (RJ-45) Ports 1 Number of SC Ports 1 Total Number of Ports 2 USB No Â
-
Fiber Mode Supported Multi-mode Fiber Optic Wavelength 1310 nm Maximum Distance Supported (mm) 0 Network Technology 10/100Base-TX, 1000Base-FX Â
-
Ethernet Technology Fast Ethernet Â
-
Depth 3" Depth (mm) 69.85 Form Factor Desktop Mount Width 5" Width (mm) 119.38 Â
-
Environmental Certification WEEE Environmentally Friendly Yes Package Contents - 10/100 SC Singlemode Media Converter, 15km, 1310nm
- External Power Supply
- Owner's Manual
Â
