Eaton Tripp Lite SMART1000RM1UN SmartPro 120V 1KVA 800W Line-Interactive Sine Wave UPS, 1U Rack/Vertical, WEBCARDLX Network Interface, USB, DB9, Outlets
SMART1000RM1UN | TC-SMART1RM
Please sign in to view pricing and availability and to add to cart.
Product Overview
The SMART1000RM1UN SmartPro 120V 1kVA 800W Line-Interactive Sine Wave UPS provides battery backup and AC power protection against blackouts, brownouts, power surges and line noise that can damage electronics or destroy data. Ideal for backing up data centers, VoIP systems and network closets, the SMART1000RM1UN switches to 1kVA/800W battery mode in milliseconds to keep your connected equipment running long enough to save files and shut down safely with no data loss.
Two of the six NEMA 5-15R outlets may be switched off remotely to reboot equipment or shed nonessential loads to maximize battery backup time for mission-critical equipment. The internal battery provides 14 minutes of support at half load (400W) and four minutes at full load (800W).
The Java-free HTML5-based WEBCARDLX interface enables full remote access for site power and UPS status monitoring, configuration, control and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities. Protocols supported include HTTP, HTTPS, SMTP, SNMPv1, SNMPv2, SNMPv3, telnet, SSH, FTP, DHCP and NTP.
Automatic voltage regulation (AVR) maintains 120V nominal output over an input range of 83V to 147V without using battery power. EMI/RFI noise filtering improves your equipment's performance and prevents damage.
Main Features
- 1kVA 800W Line-Interactive Sine wave UPS
- 6 NEMA 5-15R Outlets with 450 J surge protection
- 10' Power Cord with 120V NEMA 5-15P input
- Supports half load for 14 min, full load for 4 min
- Hot-swap field replacement internal batteries
- Pre-installed WEBCARDLX for remote access
- Auto Probe for autonomous device management
- Switchable Outlets with 2 load banks
- Automatic Voltage Regulation (AVR)
- EMI / RFI Line noise filtering
General Information
Specifications
-
ADI Part Number TC-SMART1RM Brand Name Eaton Tripp Lite Manufacturer Eaton Manufacturer Part Number SMART1000RM1UN Packaged Quantity 1 Product Line SmartPro Product Model SMART1000RM1UN Product Name SmartPro SMART1000RM1UN 1kVA Rack-mountable Product Type Line-interactive UPS Sector Data Comm & Networking Weight 32lb
-
Number of Outlets 6 Output Voltage 120V AC Receptacle Detail 6 x NEMA 5-15R Receptacle Type NEMA 5-15R
-
TAA Compliant Yes
-
Depth 16.8" Form Factor Rack Mount Height 1.7" Rack Height 1U Width 17.5"
-
Input Voltage 120V AC Waveform Type Sine Wave
-
Limited Warranty 2-Year
-
Country of Origin TW Environmental Certification RoHS Environmentally Friendly Yes Package Contents - SMART1000RM1UN SmartPro 120V 1kVA 800W Line-Interactive Sine Wave UPS
- Pre-installed WEBCARDLX network interface
- USB cables
- DB9 cable
- EPO cable
- Mounting hardware
- Owner’s manual
