Eaton Tripp Lite SMART2200RM2UL SmartPro 120V 2.2KVA 1.92KW Line-Interactive Sine Wave UPS, Lithium Iron Phosphate (LiFePO4) Batteries, 2U, LCD, USB, DB9
SMART2200RM2UL
|TC-SMART22
Shop All Eaton Tripp Lite
Eaton Tripp Lite SMART2200RM2UL SmartPro 120V 2.2KVA 1.92KW Line-Interactive Sine Wave UPS, Lithium Iron Phosphate (LiFePO4) Batteries, 2U, LCD, USB, DB9
SMART2200RM2UL | TC-SMART22
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
The SMART2200RM2UL SmartPro 120V 2.2kVA 1.92kW Line-Interactive Sine Wave UPS provides battery backup and AC power protection against blackouts, brownouts, power surges and line noise that can damage electronics or destroy data. Ideal for backing up servers and network storage devices, the SMART2200RM2UL switches to 2.2kVA/1.92kW battery mode in milliseconds to keep your connected equipment running long enough to save files and shut down safely with no data loss. The innovative lithium iron phosphate (LiFePO4) internal battery more than doubles the service life of an equivalent lead acid battery, and offers up to three times more charge/discharge cycles. It recharges to 100-percent capacity in less than two hours, making the SMART2200RM2UL an ideal backup in case of power outage. It provides 11.7 minutes of support at half load and 5.1 minutes at full load. Featuring eight outlets and a 10' (3.1m) power cord with NEMA 5-20P input, the SMART2200RM2UL maintains 120V nominal output over an input range of 83V to 147V without using battery power. EMI/RFI noise filtering improves your equipment's performance and prevents damage. A 570-joule surge suppression rating protects your equipment from harmful power surges. With free downloadable PowerAlert software (available via free download), the SMART2200RM2UL enables safe unattended system shutdown and file saves in case of a prolonged power failure.
Specifications
ADI Part Number TC-SMART22 Brand Name Eaton Tripp Lite Manufacturer Eaton Manufacturer Part Number SMART2200RM2UL Packaged Quantity 1 Product Line SmartPro Product Model SMART2200RM2UL Product Name SmartPro SMART2200RM2UL 2200VA UPS Product Type Line-interactive UPS Sector Data Comm & Networking
Application/Usage Network Storage Device, Server Backup/Run Time (Full Load) 5.1-Minute Backup/Run Time (Half Load) 11.7-Minute EMI/RFI Noise Filter Yes Hot Swappable Yes Output Voltage 110V AC, 115V AC, 120V AC Phase Single Phase Receptacle Detail 4 x NEMA 5-15/20R, 4 x NEMA 5-20 Receptacle Type NEMA 5-15/20R, NEMA 5-20 Transfer Time 5-Millisecond
Battery Recharge Time 1.4-Hour
Maximum Operating Temperature 122°F (50°C) Sound Emission 45 dB Thermal Dissipation 393.59W
Serial Port Yes
Alarm Low Battery, Overload, Power Failure, Remote Shutdown, UPS Fault, UPS StartUp
Depth 17.3" Form Factor Rack Mount Height 3.4" Rack Height 2U Weight 41.78lb Width 19.4"
Input Voltage 120V AC Plug/Connector Type NEMA 5-20P Surge Energy Rating 570 J Waveform Type Sine Wave
Mount Type Rack Mount
Limited Warranty 2-Year
Country of Origin CN Environmental Certification RoHS Environmentally Friendly Yes Package Contents - SMART2200RM2UL SmartPro 120V 2.2kVA 1.92kW Line-Interactive Sine Wave UPS
- USB cable
- DB9 cable
- EPO cable
- Rack-mounting hardware
- Owner’s manual
