Tripp Lite SRN3RG12UHD SmartRack Industrial Enclosure, Wall Mount, Locking, Fan with Thermal Switch, 32.5" Depth, 12U, NEMA 3R, Heavy-Duty Metal, Gray
SRN3RG12UHD
|TC-SRN3R12U
Shop All Eaton Tripp Lite
Tripp Lite SRN3RG12UHD SmartRack Industrial Enclosure, Wall Mount, Locking, Fan with Thermal Switch, 32.5" Depth, 12U, NEMA 3R, Heavy-Duty Metal, Gray
SRN3RG12UHD | TC-SRN3R12U
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
This SmartRack industrial enclosure is designed to house 12U of 19" rack-mount equipment, such as UPS systems and related battery packs and cabling. Constructed from heavy-duty steel with a durable gray powder-coated finish, the SRN3RG12UHD has a maximum load capacity of 200 lb (90.7 kg) and is suitable for indoor and outdoor applications. The SRN3RG12UHD protects its contents against the ingress of water (including rain, sleet and snow), solid foreign objects (including falling dirt) and even ice forming on the outside of the enclosure. It is ideal for a multitude of industrial sites, such as factories, construction areas, utility plants, power stations, transportation terminals, distribution hubs, warehouses and other areas where you need to keep sensitive equipment secure, organized and out of the way. The fully welded steel housing locks securely with the included keys to protect its contents against theft, tampering, dust and other contaminants. The weather-sealed doors allow easy access to equipment and cabling during installation and maintenance. Data and power cables may be routed through a bottom conduit cutout. This 12U industrial enclosure comes fully assembled and ready to mount to the wall with user-supplied hardware. Front and rear mounting rails adjust independently to accommodate equipment up to 32.5" deep. Hardware for mounting equipment inside the enclosure is included. Two top-mounted fans with thermal switch activate when the temperature inside the enclosure reaches 86°F (30°C). Keeping rack equipment cool helps prevent damage and ensure optimum performance.
Specifications
ADI Part Number TC-SRN3R12U Brand Name Eaton Tripp Lite Manufacturer Eaton Manufacturer Part Number SRN3RG12UHD Product Line SmartRack Product Model SRN3RG12UHD Product Name SmartRack SRN3RG12UHD Rack Mount Enclosure Product Type Rack Mount Enclosure
Application/Usage Computer, DVR, Patch Panel, PDU, Server, Switch, UPS Material Metal, Steel
Color Gray Depth 36.1" Form Factor Wall Mount Height 29.8" Weight 216.85lb Width 26.9"
Mount Type Wall Mount
Limited Warranty 5-Year
Country of Origin CN Environmentally Friendly Yes Features Adjustable Mounting Rails, Anti-theft, Cable Management, Lockable Door Indoor/Outdoor Indoor, Outdoor Package Contents - SRN3RG12UHD Industrial Enclosure
- (48) 10-32 screws
- (48) M6 washers
- (6) LDPE sheet metal plugs
- (6) M10 foam washers
- (2) Keys
- Owner's manual
