Eaton Tripp Lite U330F-30M-G1 USB 3.2 Gen 1 CL3-Rated Fiber Active Optical Cable (AOC), Extension/Repeater, A M/F, 30m (98'), Black
U330F-30M-G1
|TC-U330F30MG
Shop All Eaton Tripp Lite
Eaton Tripp Lite U330F-30M-G1 USB 3.2 Gen 1 CL3-Rated Fiber Active Optical Cable (AOC), Extension/Repeater, A M/F, 30m (98'), Black
U330F-30M-G1 | TC-U330F30MG
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
Active Optical Cable Extension Connects Servers, Hard Drives and Other USB ComponentsThis USB 3.2 Gen 1 extension/repeater cable (M/F) attaches to your current USB cable to extend your USB connection by 30 meters (98 feet). The U330F-30M-G1 connects computers, servers, external hard drives, surveillance cameras and other devices with a USB-A port.Note: You must first connect the USB-A male connector, then the USB-A female connector.Supports USB 3.2 Gen 1 Speeds for Reliably Fast Data TransfersThis cable supports USB 3.2 Gen 1 data transfer rates up to 5 Gbps, which is 10 times faster than USB 2.0. If you need an extra signal boost, connect the cable’s USB Micro-B port to a laptop, hub or USB wall charger with the included cable.Note: This USB cable is not backward compatible with USB 2.0 or USB 1.1 devices.Active Optical Cables Are Easier to Install than CopperBecause the fiber cable is slimmer and more flexible than standard copper USB cables, the U330F-30M-G1 is easier to install around corners and in hard-to-reach spaces behind equipment. It also transmits USB signals over longer distances than copper with no signal loss.30 m (98 ft.) Cable Lets You Design an Application to Your Custom SpecificationsThis long cable allows you greater flexibility in placing your USB components. For instance, your desktop computer may be connected to a security camera or a server located in a different room away from your office or in a central location where others have access to it. Premium Construction for Superior PerformanceThe PVC jacket carries a CL3 rating, making it suitable for in-wall cable installation in residential or commercial settings. Gold-plated contacts provide maximum conductivity and minimum data loss to guarantee a clear transmission free of interference. The plug-and-play U330F-30M-G1 supports all major operating systems, including Windows, macOS and Linux.
Main Features
- USB 3.2 Gen 1 Extension up to 30 m
- Supports data transfer rates up to 5 Gbps
- Slim, flexible fiber Cable for easy installation
- Not backward compatible with USB 2.0/1.1
- CL3-rated PVC jacket for in-wall installation
- Gold-Plated contacts for clear transmission
- Compatible with Windows, macOS, and Linux
- Plug-and-play design for easy use
General Information
Name: Eaton Tripp Lite U330F-30M-G1 USB 3.2 Gen 1 CL3-Rated Fiber Active Optical Cable (AOC), Extension/Repeater, A M/F, 30m (98'), Black
Category: Pro AV, Commercial Connector Cables, Pro USB Cables
UPC Code:
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number TC-U330F30MG Brand Name Eaton Tripp Lite Manufacturer Part Number U330F-30M-G1
American Wire Gauge 24AWG Application/Usage Commercial, Residential Connector on First End USB Type A - Female, USB Type A - Male Connector on Second End Micro USB Type B - Female Connector Plating Nickel Material PVC, Zinc Alloy
Connector Type USB Micro-B, USB Type-A
Data Transfer Rate 5 Gbit/s
Cable Length 98' Color Black Package Type Box
Limited Warranty 3-Year
Country of Origin VN Environmental Certification CE, REACH, RoHS Environmentally Friendly Yes Features 3-year limited warranty, Adds 30 m (98 ft.) to your existing connection to provide flexibility in placing devices, CL3-rated PVC cable jacket meets required standards for commercial in-wall installation, Fiber optic construction ideal for long-distance connections not supported by copper, Slim, flexible cable easily installs around corners and through hard-to-reach areas, Supports USB 3.2 Gen 1 speeds up to 5 Gbps to ensure fast data transfers Package Contents - U330F-30M-G1 USB 3.2 Gen 1 Fiber Active Optical Extension Cable, M/F, Black, 30 m (98 ft.)
- USB Micro-B to USB-A booster cable, M/M, 3 ft.
